Green rectangular circuit board with gold edge connector and black controller chip, M.2 2280 form factor

SAMSUNG

SAMSUNG 970 EVO MZ-V7E500E 500GB internal SSD

SKU CH-XZ1J-H9RYN MPN MZ-V7E500E

M.2 2280 NVMe SSD with 500GB capacity, sequential read up to 3400 MBps and write up to 2300 MBps

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity500GB
  • Memory ComponentsV-NAND 3-bit MLC
  • InterfacePCIe Gen 3.0 x4, NVMe 1.3

Options 500GB

  • Fast sequential reads up to 3400 MBps powered by PCIe Gen 3.0 x4 NVMe 1.3
  • Quick sequential writes up to 2300 MBps accelerated by Samsung TurboWrite technology
  • Responsive random read performance up to 370000 IOPS at QD32 with Phoenix controller
  • Low idle power draw of 30 mW maximum for efficient operation
  • Reliable endurance rated at 1500000 hours MTBF for long-term use

970 EVO 500GB NVMe Drive

The Samsung 970 EVO MZ-V7E500E is a 500GB internal SSD built for consumer PCs. It uses a PCIe Gen 3.0 x4 interface with NVMe 1.3 protocol and V-NAND 3-bit MLC memory. A Samsung Phoenix controller and 512MB Low Power DDR4 SDRAM cache manage data flow.

M.2 2280 Form Factor

The drive fits a standard M.2 2280 slot, meaning it mounts directly on the motherboard without cables. Sequential reads reach up to 3400 MBps and writes up to 2300 MBps. Random read IOPS hit 370,000 at QD32 and 15,000 at QD1. Random write IOPS reach 450,000 at QD32 and 50,000 at QD1. Dynamic Thermal Guard protects against overheating between 0°C and 70°C. Active power averages 5.7W with a 10W burst maximum.

Compatibility Check

Verify your motherboard has an M.2 slot wired for PCIe Gen 3.0 x4 and NVMe support. Confirm the BIOS can boot from an NVMe device if this will be the OS drive. Ensure the slot accepts 2280-length modules and that clearance allows the drive to seat fully. Samsung Magician software is available for monitoring and maintenance.

Highlights

  • Fast sequential reads up to 3400 MBps powered by PCIe Gen 3.0 x4 NVMe 1.3
  • Quick sequential writes up to 2300 MBps accelerated by Samsung TurboWrite technology
  • Responsive random read performance up to 370000 IOPS at QD32 with Phoenix controller
  • Low idle power draw of 30 mW maximum for efficient operation
  • Reliable endurance rated at 1500000 hours MTBF for long-term use

Specifications

BrandSAMSUNG
Series970 EVO
ModelMZ-V7E500E
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity500GB
Memory ComponentsV-NAND 3-bit MLC
InterfacePCIe Gen 3.0 x4, NVMe 1.3
ControllerSamsung Phoenix
Cache512MB Low Power DDR4 SDRAM
Max Sequential ReadUp to 3400 MBps
Max Sequential WriteUp to 2300 MBps
4KB Random ReadQD32: Up to 370,000 IOPS
QD1: Up to 15,000 IOPS
4KB Random WriteQD32: Up to 450,000 IOPS
QD1: Up to 50,000 IOPS
MTBF1,500,000 hours
FeaturesNon-Volatile Memory Express (NVMe)
970 EVO 500GB NVMe SSDs with a newly enhanced Phoenix controller outperform our previous 960 EVO 500GB model with exceptionally fast sequential read/write speeds up to 3,400/2,300 MB/s. They also support PCI Express (PCIe) Gen 3 x4 lanes to provide high bandwidth and low latency, making them perfect for business professionals who need cutting edge-performance for high-end computing.
TurboWrite Technology
Samsung's intelligent TurboWrite technology helps to maximize your computing ability, accelerating write speeds above and beyond the already except
Power Consumption (Idle)30 mW (max)
Power Consumption (Active)Average: 5.7W / Maximum: 10W (Burst mode)
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,500G & 0.5 ms (Half sine)
Height2.38mm
Width22.15mm
Depth80.15mm
Weight8.00g
Shipping weight0.08 kg
Package size141 × 98 × 24 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What PCIe generation and NVMe version does the 970 EVO 500GB use, and what sequential speeds does that cap?

The drive uses PCIe Gen 3.0 x4 with NVMe 1.3, capping sequential read at 3400 MBps and sequential write at 2300 MBps.

What M.2 form factor and keying does the MZ-V7E500E need to fit?

It uses the M.2 2280 form factor, so the motherboard slot must accept 80 mm length modules.

How is the Samsung 970 EVO installed, and which step is often missed?

Insert the drive at an angle into the M.2 slot, press down, and secure it with the retention screw; people often forget the screw.
