Green rectangular M.2 2280 SSD circuit board with black chips and gold edge connector

SanDisk

SanDisk Optimus GX 7100 4TB M.2 2280-S3-M internal SSD SDSP71400TAN-000E0

SKU CH-6NP1-TNS8F MPN SDSP71400TAN-000E0

4 TB M.2 2280-S3-M internal SSD with PCI-Express 4.0 x4 interface, NVMe 2.0 protocol, up to 7000 MBps sequential read, 6700 MBps sequential write, 900000 IOPS random read.

  • Device TypeInternal Solid State Drive (SSD)
  • Form FactorM.2 2280-S3-M
  • Capacity4TB
  • Memory Components3D NAND TLC
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe 2.0

Capacity 4TB

  • Sequential reads up to 7000 MBps for fast game loading
  • Sequential writes up to 6700 MBps to handle large file transfers
  • Random reads up to 900000 IOPS for snappy system response
  • Random writes up to 1350000 IOPS to reduce in-game stutter
  • 2400 TBW endurance rating for long-term reliability

4TB PCIe 4.0 NVMe drive

The SanDisk Optimus GX 7100 is a 4TB internal SSD built to the M.2 2280-S3-M form factor. It connects over a PCI-Express 4.0 x4 link using the NVMe 2.0 protocol. The drive uses 3D NAND TLC memory and ships without a heatsink.

Suits PCIe 4.0 slots with 4TB needs

This drive fits desktops and laptops that have an M.2 2280 slot wired for PCIe 4.0 x4 and can accommodate a single-sided module. Systems limited to PCIe 3.0 or shorter M.2 keys will not reach the stated speeds. Builds that require a factory-fitted heatsink should consider other models.

Check slot key length and thermal plan

Verify the motherboard or laptop provides an M.2 2280-S3-M socket with PCIe 4.0 x4 electrical wiring. Confirm the operating temperature range of 0 to 85 °C matches the chassis airflow. Ensure the firmware supports NVMe 2.0 features before installation.

Highlights

  • Sequential reads up to 7000 MBps for fast game loading
  • Sequential writes up to 6700 MBps to handle large file transfers
  • Random reads up to 900000 IOPS for snappy system response
  • Random writes up to 1350000 IOPS to reduce in-game stutter
  • 2400 TBW endurance rating for long-term reliability

Specifications

BrandSanDisk
SeriesOptimus GX 7100
ModelSDSP71400TAN-000E0
Device TypeInternal Solid State Drive (SSD)
Form FactorM.2 2280-S3-M
Capacity4TB
Memory Components3D NAND TLC
InterfacePCI-Express 4.0 x4
ProtocolNVMe 2.0
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 6700 MBps
4KB Random ReadUp to 900,000 IOPS
4KB Random WriteUp to 1,350,000 IOPS
Terabytes Written (TBW)2400TB
MTBF1,750,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)5 mW
Power Consumption (Active)Average Active Power Read: 4.1W
Average Active Power Write: 4.0W
Operating Temperature0°C ~ +85°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1,500G @ 0.5 ms half-sine
Max Vibration ResistanceOperating Vibration: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating Vibration: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22mm
Depth80mm
Weight5.8g
Shipping weight0.05 kg
Package size127 × 102 × 22 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What M.2 slot key and length does my motherboard need for the Optimus GX 7100 4TB?

The drive uses the M.2 2280-S3-M form factor, so the slot must accept 80 mm modules with an M-key connector.

Will the Optimus GX 7100 run at full speed in a PCIe 3.0 x4 slot?

It is a PCIe 4.0 x4 NVMe 2.0 drive; in a 3.0 slot it will operate at PCIe 3.0 speeds instead of the rated 7000 MBps read and 6700 MBps write.

How can I verify the Optimus GX 7100 is delivering its rated random performance after installation?

Run a 4 KB random read/write test and look for results near 900,000 IOPS read and 1,350,000 IOPS write.
