Green circuit board with black controller and memory chips, M.2 2280 form factor, no heatsink

SanDisk

SanDisk Optimus GX 7100 500GB M.2 2280-S3-M PCIe 4.0 x4 NVMe internal SSD SDSP71500GAN-000E0

SKU CH-DXP0-4G8N7 MPN SDSP71500GAN-000E0

500 GB PCIe 4.0 NVMe SSD delivering 6800 MB/s read and 5800 MB/s write for fast gaming and creative workloads

  • Device TypeInternal Solid State Drive (SSD)
  • Form FactorM.2 2280-S3-M
  • Capacity500GB
  • Memory Components3D NAND TLC
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe 2.0

Capacity 500G

  • Sequential reads up to 6800 MB/s for fast game loads
  • Sequential writes up to 5800 MB/s for quick installs
  • Random reads up to 760000 IOPS for responsive gameplay
  • Random writes up to 1200000 IOPS for smooth multitasking
  • 300 TBW endurance rating for long-term reliability

Capacity and interface

The SanDisk Optimus GX 7100 is a 500GB internal solid state drive using the M.2 2280-S3-M form factor. It connects through a PCI-Express 4.0 x4 interface running the NVMe 2.0 protocol. The drive employs 3D NAND TLC memory components and ships without a heatsink.

Who this suits

This SSD suits PC builders and laptop owners who want faster game loading and responsive creative workflows on a PCIe 4.0 platform. The power-efficient design draws 5 mW idle and around 3.5 W active, making it practical for handheld gaming consoles and thin notebooks. Buyers who need a heatsink pre-installed or who require higher endurance than 300 TBW should consider other options.

Deciding specification

The single specification that decides fit is the M.2 2280-S3-M form factor combined with the PCI-Express 4.0 x4 interface. Your motherboard or device must provide an M-keyed slot wired for four lanes of PCIe 4.0 to achieve the stated 6800 MBps read and 5800 MBps write speeds.

Highlights

  • Sequential reads up to 6800 MB/s for fast game loads
  • Sequential writes up to 5800 MB/s for quick installs
  • Random reads up to 760000 IOPS for responsive gameplay
  • Random writes up to 1200000 IOPS for smooth multitasking
  • 300 TBW endurance rating for long-term reliability

Specifications

BrandSanDisk
SeriesOptimus GX 7100
ModelSDSP71500GAN-000E0
Device TypeInternal Solid State Drive (SSD)
Form FactorM.2 2280-S3-M
Capacity500GB
Memory Components3D NAND TLC
InterfacePCI-Express 4.0 x4
ProtocolNVMe 2.0
Max Sequential ReadUp to 6800 MBps
Max Sequential WriteUp to 5800 MBps
4KB Random ReadUp to 760,000 IOPS
4KB Random WriteUp to 1,200,000 IOPS
Terabytes Written (TBW)300TB
MTBF1,750,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)5 mW
Power Consumption (Active)Average Active Power Read: 3.4W
Average Active Power Write: 3.5W
Operating Temperature0°C ~ +85°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1,500G @ 0.5 ms half-sine
Max Vibration ResistanceOperating Vibration: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating Vibration: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22mm
Depth80mm
Weight5.8g
Shipping weight0.05 kg
Package size127 × 102 × 18 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the SanDisk Optimus GX 7100 500GB include a heatsink or mounting screw, or must they be bought separately?

The drive ships without a heatsink. A motherboard M.2 mounting screw is also not included; reuse the screw from your board or purchase one separately.

How do I decide between the 500GB Optimus GX 7100 and a larger capacity in the same series?

Choose 500GB if you need a single fast NVMe drive for the OS and a handful of active titles; step up to 1TB or 2TB when your library grows beyond that footprint.

What does the 6800 MBps sequential read figure mean once the SSD is installed in my PC?

It represents the peak throughput the controller can sustain on a PCIe 4.0 x4 link; real-world game loads and file copies will typically run lower depending on workload and thermal conditions.
