A green M.2 2280 circuit board with black controller and memory chips

SanDisk

SanDisk WD_BLACK SN7100 WDS500G4X0E-00CJA0 500GB internal SSD

SKU CH-TNAN-RYZ0G MPN WDS500G4X0E-00CJA0

A 500GB M.2 2280 NVMe SSD delivering up to 6800MB/s read and 5800MB/s write with 3000TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity500GB
  • Memory ComponentsTLC 3D NAND
  • InterfacePCI-Express 4.0 x4

Style Faster

Options 500GB

  • Fast game loads with up to 6800 MB/s sequential read
  • Quick level streaming via up to 5800 MB/s sequential write
  • Responsive multitasking from 760,000 IOPS random read
  • Sustained heavy writes backed by 1,200,000 IOPS random write
  • Long service life rated at 3000 TBW endurance

WD_BLACK SN7100 500GB gaming SSD

The WD_BLACK SN7100 is a 500GB internal solid state drive built for consumer PCs and handheld gaming devices. It uses a PCI-Express 4.0 x4 interface with the NVMe protocol and TLC 3D NAND flash. Sequential reads reach up to 6800 MBps and writes up to 5800 MBps.

DRAM-less M.2 2280 design

The drive adopts the M.2 2280 form factor and operates without a dedicated DRAM cache, relying on host memory buffer technology. It ships without a heatsink, so it fits thin laptop slots and compact handhelds where clearance is tight. Idle power draw in sleep state is 5mW.

Upgrade from older Gen4 drives

This model delivers up to 35% faster performance than the previous generation and up to 100% better power efficiency for mobile use. Endurance is rated at 3000TB written with a 1,750,000 hour MTBF. The WD_BLACK Dashboard utility on Windows helps maintain peak operation.

Highlights

  • Fast game loads with up to 6800 MB/s sequential read
  • Quick level streaming via up to 5800 MB/s sequential write
  • Responsive multitasking from 760,000 IOPS random read
  • Sustained heavy writes backed by 1,200,000 IOPS random write
  • Long service life rated at 3000 TBW endurance

Specifications

BrandWestern Digital
SeriesSN7100
ModelWDS500G4X0E
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity500GB
Memory ComponentsTLC 3D NAND
InterfacePCI-Express 4.0 x4
ProtocolNVMe
CacheNo DRAM (HMB)
Max Sequential ReadUp to 6800 MBps
Max Sequential WriteUp to 5800 MBps
4KB Random ReadUp to 760,000 IOPS
4KB Random WriteUp to 1,200,000 IOPS
Terabytes Written (TBW)3000TB
MTBF1,750,000 hours
HeatSinkwithout HeatSink
FeaturesHIGH-OCTANE GAMING. Experience speeds up to 7,250MB/s read and 6,900MB/s write (1-2TB models), with up to 35% faster performance than previous generation.
PURPOSE-BUILT. Designed for serious on-the-go gamers, with a PCIe Gen4 interface and Western Digital's next generation TLC 3D NAND.
MORE SPACE FOR FAVORITES AND NEW TITLES. Available in multiple capacities up to 2TB, upgrade to an SSD that gives you tons of storage.
MORE TIME TO CLEAR THAT CHECKPOINT. Built with laptops and handheld gaming devices in mind, with up to 100% more power efficiency over the previous generation.
DO MORE
Power Consumption (Idle)Sleep (PS4): 5mW
Power Consumption (Active)Average Active Power: 95mW
Maximum Operating Power: 4.5W
Operating Temperature32°F to 185°F (0°C to 85°C)
Storage Temperature-40°F to 185°F (-40°C to 85°C)
Max Shock Resistance1,500G @0.5 ms half sine
Max Vibration Resistance5 gRMS, 10-2000 Hz, 3 axes
Height1.14mm
Width22mm
Depth80mm
Weight5.8g
Shipping weight0.05 kg
Package size127 × 102 × 25 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this M.2 2280 drive fit my laptop’s single PCIe 4.0 slot without a heatsink?

The drive uses the M.2 2280 form factor and has no integrated heatsink, so it fits standard laptop slots that accept single-sided modules.

Does the 500 GB model deliver the 7,250 MB/s read speed shown for larger capacities?

The 500 GB version is rated for up to 6,800 MB/s sequential read and 5,800 MB/s sequential write.

Is the 3,000 TBW endurance figure enough for heavy game installs and frequent capture recording?

At 3,000 TBW the drive is built for high write workloads such as streaming captures and large game libraries.
