Silver aluminium M.2 NVMe enclosure, compact rectangular shape, USB-C port visible

SIIG, Inc

SIIG, Inc JU-SA0X11-S1 USB 3.2 Gen 2x2 M.2 NVMe drive enclosure

SKU CH-TQWV-45P8E MPN JU-SA0X11-S1

Aluminium enclosure holds one M.2 NVMe SSD and connects via USB 3.2 Gen 2x2 at up to 20 Gbps

  • ColorSilver
  • SizeM.2
  • TypeEnclosure
  • MaterialAluminum
  • Internal InterfaceM.2 NVME M-Key
  • External InterfaceUSB 3.2
  • Up to 20 Gbps transfer speed with USB 3.2 Gen 2x2
  • Tool-free M.2 NVMe installation supports 2230 2242 2260 2280 sizes
  • Aluminium body acts as heatsink for sustained performance
  • Bus-powered over USB-C so no external adapter needed
  • Works with Windows 10 8 7 and macOS 10.6 or later

M.2 NVMe enclosure for USB-C 20 Gbps

The SIIG JU-SA0X11-S1 accepts a single M-key PCIe NVMe SSD in 2230, 2242, 2260 or 2280 form factors. It connects through a USB 3.2 Gen 2x2 Type-C port and delivers up to 20 Gbps when paired with a compatible host controller. The ASMedia 2364 chipset handles the PCIe 3.0 x 4 to USB translation. No SATA M.2 drives are supported.

Aluminium shell with bus power and thermal pad

The silver aluminium body measures 0.59 by 4.84 by 1.81 inches and weighs 0.25 lb. Power comes entirely from the USB-C bus at 5 V, so no external adapter is needed. A thermal pad is included to conduct heat from the drive to the enclosure surface. UASP and hot-plug are both supported for everyday attach and detach cycles.

Upgrade from USB 3.1 or 3.0 enclosures

Builders moving from a 10 Gbps or 5 Gbps enclosure gain the full 20 Gbps ceiling when the host side also supports USB 3.2 Gen 2x2. The jump is worthwhile for large sequential transfers such as video offload or disk imaging. Users whose ports top out at 10 Gbps will see no speed benefit over a Gen 2 enclosure.

Highlights

  • Up to 20 Gbps transfer speed with USB 3.2 Gen 2x2
  • Tool-free M.2 NVMe installation supports 2230 2242 2260 2280 sizes
  • Aluminium body acts as heatsink for sustained performance
  • Bus-powered over USB-C so no external adapter needed
  • Works with Windows 10 8 7 and macOS 10.6 or later

Specifications

BrandSIIG
ModelJU-SA0X11-S1
ColorSilver
SizeM.2
TypeEnclosure
MaterialAluminum
Internal InterfaceM.2 NVME M-Key
External InterfaceUSB 3.2
HDD Count SupportedSingle SSD
Number of Bay1
PowerUSB-C Bus-powered (5V)
SpecificationsChipset: ASMedia 2364
Compliant with USB 3.2 Gen 2x2 specification revision 1.0
Compatible with PCIe 3.0 x 4 specification
USB data transfer rate: Up to 20Gbps
SSD type (not included): M.2 PCIe NVMe SSD (M Key). Note: Not compatible with M.2 SATA SSDs
SSD size: 2230 / 2242 / 2260 / 2280mm
Power source: USB-C Bus-powered (5V)
UASP: Yes
Hot plug: Yes
Operating Systems SupportedWindows 10 / 8 / 7 macOS 10.6 or later
FeaturesThis ultra small enclosure easily adds fast M.2 (M key) PCIe NVMe SSD storage to your Windows or Mac computers through USB 3.2 Gen 2x2 USB-C port.
Ultra-fast data transfer rate up to 20Gbps through USB 3.2 Gen 2x2 with UASP technology. Requires UASP compatible USB 3.2 Gen 2 2x2 host controller hardware along with Windows 10 and Windows 8 USB 3.2 host controller drivers.
Compliant with SuperSpeed USB 20Gbps / 10Gbps / 5Gbps, High Speed 480Mbps, and Full Speed 12Mbps.
Accommodates 2230, 2242, 2260, and 2280 form factor M-Key M.2 PCIe NVMe SSD. Note: Does NOT work with B-key M.2 PCIe NV
Dimensions0.59" x 4.84" x 1.81"
Weight0.25 lb.
Package ContentsUSB 3.2 Gen 2x2 Type-C 20G NVMe SSD Enclosure
USB 3.2 Gen 2x2 USB-C to USB-C cable
Thermal pad
User Manual
Shipping weight0.27 kg
Package size133 × 108 × 56 mm

Questions about this item

What USB 3.2 Gen 2x2 speed does the enclosure cap at in practice?

The USB 3.2 Gen 2x2 interface supports up to 20Gbps data transfer with UASP enabled.

Which M.2 drive lengths fit inside the aluminium case?

The enclosure accepts M.2 PCIe NVMe SSDs in 2230, 2242, 2260 and 2280 mm sizes using the M-key slot.

How is the drive secured and what step is often missed?

Insert the M.2 NVMe SSD at an angle into the M-key slot, press down and fasten the screw; apply the included thermal pad to the controller before closing the aluminium cover.
