Solidigm D5-P5336 E3.S 7.5mm enterprise SSD, green circuit board with silver label and gold edge connector

Solidigm

Solidigm D5-P5336 SBFPFABV076T001 7.68TB enterprise SSD

SKU CH-3CZV-88WG5 MPN SBFPFABV076T001

E3.S 7.5mm PCIe 4.0 x4 drive with 7.68TB QLC 3D NAND, 6800 MBps read, 1800 MBps write, 0.42 DWPD endurance and 2,000,000-hour MTBF

  • Form FactorE3.S 7.5mm
  • Capacity7.68TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 6800 MBps
  • Max Sequential WriteUp to 1800 MBps

Option 7.68TB E3.S

  • 122.88TB E1.L
  • 122.88TB E1.L FIPS
  • 122.88TB U.2
  • 122.88TB U.2 FIPS
  • 122.88TB U.2 Opal
  • 15.36TB E1.L
  • 15.36TB E1.L FIPS
  • 15.36TB E3.S
  • 15.36TB E3.S FIPS
  • 15.36TB E3.S Opal
  • 15.36TB U.2
  • 15.36TB U.2 FIPS
  • 15.36TB U.2 Opal
  • 30.72TB E1.L
  • 30.72TB E1.L FIPS
  • 30.72TB E3.S
  • 30.72TB E3.S FIPS
  • 30.72TB E3.S Opal
  • 30.72TB U.2
  • 30.72TB U.2 FIPS
  • 30.72TB U.2 Opal
  • 61.44TB E1.L
  • 61.44TB E1.L 10PK
  • 61.44TB E1.L FIPS
  • 61.44TB U.2
  • 61.44TB U.2 FIPS
  • 61.44TB U.2 Opal
  • 7.68TB E3.S
  • 7.68TB E3.S FIPS
  • 7.68TB E3.S Opal
  • 7.68TB U.2
  • 7.68TB U.2 FIPS
  • 7.68TB U.2 Opal

Struck-through versions exist but are not stocked here.

  • High capacity for read-heavy workloads with 7.68TB QLC storage
  • Fast sequential reads up to 6800 MBps via PCIe 4.0 x4
  • High random read performance reaching 770000 IOPS at QD256
  • Proven reliability rated at 2,000,000 hours MTBF
  • Efficient power use at 5W idle and 15W active

High-capacity E3.S enterprise SSD

The Solidigm D5-P5336 provides 7.68TB of storage in an E3.S 7.5mm form factor. It uses a PCI-Express 4.0 x4 interface and 192-layer QLC 3D NAND. Sequential reads reach up to 6800 MBps while sequential writes reach up to 1800 MBps.

Suited for read-heavy server workloads

This drive targets data-centre deployments that prioritise capacity and read throughput, such as content delivery or warm data tiers. Its 0.42 DWPD endurance rating and 17900 IOPS random write performance make it a poor fit for write-intensive databases or high-transaction logging.

Fits E3.S bays with 15W active power

Installation requires a server chassis or backplane that accepts the E3.S 7.5mm form factor and supplies a PCIe 4.0 x4 link. The 5W idle and 15W active power draw helps thermal planning, while the 90g weight adds minimal load to dense drive trays.

Highlights

  • High capacity for read-heavy workloads with 7.68TB QLC storage
  • Fast sequential reads up to 6800 MBps via PCIe 4.0 x4
  • High random read performance reaching 770000 IOPS at QD256
  • Proven reliability rated at 2,000,000 hours MTBF
  • Efficient power use at 5W idle and 15W active

Specifications

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV076T001
Form FactorE3.S 7.5mm
Capacity7.68TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 6800 MBps
Max Sequential WriteUp to 1800 MBps
4KB Random Read770000 IOPS (4K, QD256)
4KB Random Write17900 IOPS (16K, QD256)
Endurance0.42 DWPD (16K RW) / 5.92 PBW
MTBF2,000,000 hours
Power Consumption (Idle)5W
Power Consumption (Active)15W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Shipping weight0.17 kg
Package size140 × 110 × 17 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does my server need an E3.S 7.5mm drive bay to install this 7.68TB SSD?

Yes, the drive uses the E3.S 7.5mm form factor and requires a compatible hot-plug bay or backplane with the matching connector and mechanical latch.

Will this PCIe 4.0 x4 drive run at full speed in a PCIe 3.0 slot?

It will operate at PCIe 3.0 speeds, limiting sequential reads to roughly half the 6800 MBps rating while writes and latency remain within the drive's 0.42 DWPD endurance envelope.

How can I verify the drive is healthy after installation?

Check SMART attributes for media and data integrity errors, confirm the firmware reports 7.68TB capacity, and ensure idle power sits near 5W and active power near 15W under load.
