Thin green E3.S 7.5mm enterprise SSD with gold edge connector and label

Solidigm

Solidigm D5-P5430 30.72TB E3.S 7.5mm PCIe 4.0 enterprise SSD SBFPFABU307TOP1

SKU CH-93ZF-GV73V MPN SBFPFABU307TOP1

30.72 TB enterprise SSD in E3.S 7.5 mm form factor with PCIe 4.0 x4, 192-layer QLC 3D NAND, up to 7000 MB/s sequential read, 3000 MB/s sequential write, 971000 IOPS random read.

  • Form FactorE3.S 7.5mm
  • Capacity30.72TB
  • Memory Components192L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 7000 MBps
  • Max Sequential WriteUp to 3000 MBps

Option 30.72TB E3.S Opal

Show 14 more configurations

Struck-through versions exist but are not stocked here.

  • Massive 30.72 TB capacity fits huge datasets in one E3.S drive
  • PCIe 4.0 x4 interface delivers up to 7000 MB/s sequential read speed
  • 192-layer QLC 3D NAND provides 971,000 random read IOPS for heavy read workloads
  • 2,000,000-hour MTBF and 31.22 PBW endurance ensure long-term data-centre reliability
  • Opal encryption and 5 W idle power protect data while reducing rack energy use

Enterprise storage density

The Solidigm D5-P5430 is a 30.72TB enterprise SSD built in the E3.S 7.5mm form factor for PCIe 4.0 x4 servers. It targets data-centre operators who need maximum capacity per drive bay for read-intensive workloads such as content delivery, warm storage and analytics repositories.

Capacity headroom and write limits

The drive delivers up to 7000 MBps sequential read and 971000 random read IOPS, so large datasets stream quickly. Sequential write peaks at 3000 MBps and random write at 85000 IOPS, while endurance is rated at 0.56 DWPD or 31.22 PBW, meaning sustained heavy write traffic will exhaust the budget well before the five-year horizon.

E3.S 7.5mm form factor fit

This drive only fits bays and backplanes designed for the E3.S 7.5mm standard; it will not install in U.2, U.3, M.2 or taller E3.S slots. Verify the chassis supports PCIe 4.0 x4 wiring and the 7.5mm z-height before ordering.

Highlights

  • Massive 30.72 TB capacity fits huge datasets in one E3.S drive
  • PCIe 4.0 x4 interface delivers up to 7000 MB/s sequential read speed
  • 192-layer QLC 3D NAND provides 971,000 random read IOPS for heavy read workloads
  • 2,000,000-hour MTBF and 31.22 PBW endurance ensure long-term data-centre reliability
  • Opal encryption and 5 W idle power protect data while reducing rack energy use

Specifications

BrandSolidigm
ModelD5-P5430
Part NumberSBFPFABU307TOP1
Form FactorE3.S 7.5mm
Capacity30.72TB
Memory Components192L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random Read971000 IOPS (4K, QD256)
4KB Random Write85000 IOPS (8K, QD256)
EnduranceUp to 0.56 DWPD (8K RW) / Up to 31.22 PBW
MTBF2,000,000 hours
SecurityOpal
Power Consumption (Idle)5W
Power Consumption (Active)25W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight93.5g
Shipping weight0.17 kg
Package size140 × 110 × 17 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the E3.S 7.5mm form factor fit in my existing PCIe 3.0 server backplane?

The drive uses a PCIe 4.0 x4 interface and is electrically compatible with PCIe 3.0 slots, though sequential speeds will be limited to the 3.0 bandwidth ceiling. Physical fit depends on your chassis supporting the E3.S 7.5mm form factor.

How can I verify the drive delivers the rated 971000 IOPS random read performance after installation?

Run a 4K random read test at queue depth 256 using a tool such as FIO; sustained results near 971000 IOPS confirm the controller and 192L QLC NAND are operating as specified.

Does the single pack include a heatsink or mounting hardware for the E3.S slot?

The single pack contains only the SSD itself; any required E3.S heatsink, retention clip or cage adapter must be sourced separately from your server vendor.
