Silver 2.5 inch SATA SSD with black label showing 960GB capacity

Solidigm

Solidigm SSDSC2KB960GZ1Z D3-S4520 960GB 2.5" SATA enterprise SSD

SKU CH-7NWH-GQ9P3 MPN SSDSC2KB960GZ1Z

A 960GB 2.5" SATA enterprise SSD with 144L TLC 3D NAND, up to 550 MBps read, 510 MBps write, 90,000 read IOPS, 43,000 write IOPS, 3.0 DWPD endurance, and 2,000,000-hour MTBF

  • Form Factor2.5"
  • Capacity960GB
  • Memory Components144L TLC 3D NAND
  • InterfaceSATA III
  • Max Sequential ReadUp to 550 MBps
  • Max Sequential WriteUp to 510 MBps

Option

  • 1920GB 2.5"
  • 240GB 2.5"
  • 240GB M.2
  • 3840GB 2.5"
  • 480GB 2.5"
  • 480GB M.2
  • 7680GB 2.5"
  • 960GB 2.5"

Struck-through versions exist but are not stocked here.

  • Enterprise endurance with up to 3.0 DWPD and 5.3 PBW written
  • Fast random reads up to 90,000 IOPS for database workloads
  • Low idle power draw of 1.1W reduces server energy costs
  • 144-layer TLC 3D NAND delivers 960GB capacity in 2.5" form factor
  • Rated for 2,000,000 hours MTBF and 1,000 G shock resistance

960GB SATA enterprise SSD

The Solidigm D3-S4520 is a 2.5-inch solid-state drive built for server and data-centre workloads. It uses 144L TLC 3D NAND and a SATA III interface to deliver up to 550 MBps sequential read and 510 MBps sequential write speeds. Random performance reaches 90,000 IOPS read and 43,000 IOPS write. Endurance is rated at 3.0 DWPD or 5.3 PBW with a 2,000,000-hour MTBF.

Suited for read-intensive arrays.

This drive fits read-intensive applications such as boot volumes, content delivery and warm data tiers where the 3.0 DWPD endurance budget matches the workload. Buyers who need higher write endurance for logging, caching or database journals should look at drives with a larger DWPD rating. Systems limited to SATA II ports will not reach the quoted throughput.

3.0 DWPD endurance decides fit

The 3.0 drive writes per day rating over five years translates to 5.3 PBW total bytes written. That single figure determines whether the SSD can sustain your daily write volume without exceeding its warranty lifetime. Compare your application's average daily writes against this number before purchasing.

Highlights

  • Enterprise endurance with up to 3.0 DWPD and 5.3 PBW written
  • Fast random reads up to 90,000 IOPS for database workloads
  • Low idle power draw of 1.1W reduces server energy costs
  • 144-layer TLC 3D NAND delivers 960GB capacity in 2.5" form factor
  • Rated for 2,000,000 hours MTBF and 1,000 G shock resistance

Specifications

BrandSolidigm
ModelD3-S4520
Part NumberSSDSC2KB960GZ1Z
Form Factor2.5"
Capacity960GB
Memory Components144L TLC 3D NAND
InterfaceSATA III
Max Sequential ReadUp to 550 MBps
Max Sequential WriteUp to 510 MBps
4KB Random ReadUp to 90,000 IOPS
4KB Random WriteUp to 43,000 IOPS
EnduranceUp to 3.0 DWPD / Up to 5.3 PBW
MTBF2,000,000 hours
Power Consumption (Idle)1.1W
Power Consumption (Active)3.1W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight60.6g
Shipping weight0.18 kg
Package size140 × 108 × 13 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I verify the D3-S4520 960GB is performing correctly after installation?

Run a benchmark and confirm sequential reads near 550 MBps, sequential writes near 510 MBps, random reads near 90,000 IOPS and random writes near 43,000 IOPS.

What ships with the SSDSC2KB960GZ1Z and what must I source separately?

The drive itself is supplied in a generic single pack; a 2.5" SATA data cable, power cable and any mounting bracket are not included.

Which capacity of the D3-S4520 series should I choose for a write-heavy workload?

The 960GB model delivers up to 3.0 DWPD and 5.3 PBW endurance using 144L TLC 3D NAND.
