Silver 12-bay rackmount NAS enclosure, 3.46 inches high, front drive trays visible

Synology Inc.

Synology RX1217 12-bay rackmount NAS (diskless)

SKU CH-JGN1-13C0F MPN RX1217

Adds twelve SATA drive bays to compatible Synology RackStations for online volume expansion or local backup, managed through DSM

  • HDD Interface12 x SATA (12 x Bay)
  • PowerAC input power voltage: 100V to 240V Power frequency: 50Hz t
  • FeaturesPlug-n-use design for seamless storage space upgrade Online
  • TemperatureOperating temperature: 5 degree C to 35 degree C (40 degree
  • Humidity5-95% R.H
  • Dimensions3.46" x 16.95" x 25.35"

Option RX1217

Struck-through versions exist but are not stocked here.

  • Expand storage instantly with 12 additional drive bays
  • Expand RAID volumes online without reformatting existing drives
  • Serve as a local backup destination for RackStation data
  • Connect via high-bandwidth expansion cable for maximum throughput
  • Manage everything from Synology DiskStation Manager (DSM)

12-bay SATA expansion for RackStation

Synology RX1217 is a diskless rackmount expansion unit that adds twelve SATA drive bays to compatible Synology RackStation servers. It connects through a high-bandwidth expansion cable and is managed entirely from the host DiskStation Manager interface. The unit ships with a single AC power cord and accessory pack for immediate deployment.

Suits administrators needing raw capacity growth

Administrators who need to grow an existing RAID volume on a supported RackStation can expand it online while services continue running. The enclosure also works as a separate local backup target. It does not operate as a standalone NAS, so buyers without a compatible RackStation cannot use it. Environments requiring dual power supplies should note the redundant option is a different model.

Twelve SATA bays linked by expansion cable

The enclosure provides twelve SATA 6 Gb/s drive slots that appear to the host as if they were internal bays. Drives are hot-swappable and the volume can be expanded on the fly without downtime. Operating temperature ranges from 5 to 35 °C and the unit fits a standard rack depth of 25.35 inches.

Highlights

  • Expand storage instantly with 12 additional drive bays
  • Expand RAID volumes online without reformatting existing drives
  • Serve as a local backup destination for RackStation data
  • Connect via high-bandwidth expansion cable for maximum throughput
  • Manage everything from Synology DiskStation Manager (DSM)

Specifications

BrandSynology
ModelRX1217
HDD Interface12 x SATA (12 x Bay)
PowerAC input power voltage: 100V to 240V
Power frequency: 50Hz to 60Hz, single phase
FeaturesPlug-n-use design for seamless storage space upgrade
Online volume expansion on the fly
Redundant power supplies ensure service uptime (RX1217RP only)
Managed from Synology DiskStation Manager (DSM)
TemperatureOperating temperature: 5 degree C to 35 degree C (40 degree F to 95 degree F)
Storage temperature: -20 degree C to 60 degree C (-5 degree F to 140 degree F)
Humidity5-95% R.H
Dimensions3.46" x 16.95" x 25.35"
Weight28.00 lbs.
Package ContentsRX1217 main unit, Quick Installation Guide, accessory pack, AC power cord x 1 (RX1217), AC power cord x 2 (RX1217RP), expansion cable
Shipping weight17.92 kg
Package size851 × 622 × 229 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Which Synology RackStation models can I attach this RX1217 to for extra drive bays?

Compatible models include RS4017xs+, RS3617xs+, RS3617RPxs, RS3617xs, RS3614xs+, RS3614RPxs, RS2416RP+, RS2414RP+, RS3413xs+, RS3412RPxs, RS3411RPxs, RS2212RP+ and RS2211RP+.

Does the 12-bay unit come with the cable needed to link it to my existing RackStation?

Yes, an expansion cable is included in the package contents so you can connect the RX1217 to a supported Synology RackStation.

How can I verify the new drives in the RX1217 are recognised and the volume has expanded?

Open Synology DiskStation Manager on the host RackStation; the Storage Manager will show the additional bays, drive health and the expanded volume status.
