Black M.2 2280 SSD with angular silver heatsink and XPG branding

XPG

XPG GAMMIX S11 Pro 1TB internal SSD with heatsink

SKU CH-HZ60-KCCP2

A 1 TB internal SSD with a heatsink delivering up to 3500 MB/s read and 3000 MB/s write over PCIe 3.0 x4 NVMe 1.3

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4, NVMe 1.3

Options 1TB S11 Pro

  • Delivers sequential read speeds up to 3500 MB/s via PCIe 3.0 x4 NVMe 1.3 interface
  • Sustains sequential write speeds up to 3000 MB/s for fast game installs and large file transfers
  • Achieves 4KB random read up to 390000 IOPS and random write up to 380000 IOPS for responsive multitasking
  • Rated 640 TBW with 2000000 hours MTBF using 3D NAND for long-term endurance
  • Integrated heatsink lowers drive temperature by up to 10°C for stable performance under load

GAMMIX S11 Pro 1TB NVMe SSD with heatsink

This internal solid-state drive uses a PCIe 3.0 x4 interface and NVMe 1.3 to reach sequential reads of 3500 MB/s and writes of 3000 MB/s. It is built for gamers, overclockers and rendering professionals who need sustained speed. The integrated heatsink lowers drive temperature by up to 10 °C.

PCIe 3.0 x4 interface limits real-world throughput

The bus caps sequential bandwidth near 3500 MB/s read and 3000 MB/s write, so heavier workloads cannot exceed that ceiling. Random performance tops out at 390000 IOPS read and 380000 IOPS write. Endurance is rated at 640 TBW with a 2000000-hour MTBF.

Check M.2 2280 slot and heatsink clearance

Verify the motherboard has an M.2 2280 key-M slot wired for PCIe 3.0 x4 and NVMe 1.3. Ensure the heatsink fits under any motherboard shield or graphics card backplate. Confirm the BIOS can boot from an NVMe drive before installing.

Highlights

  • Delivers sequential read speeds up to 3500 MB/s via PCIe 3.0 x4 NVMe 1.3 interface
  • Sustains sequential write speeds up to 3000 MB/s for fast game installs and large file transfers
  • Achieves 4KB random read up to 390000 IOPS and random write up to 380000 IOPS for responsive multitasking
  • Rated 640 TBW with 2000000 hours MTBF using 3D NAND for long-term endurance
  • Integrated heatsink lowers drive temperature by up to 10°C for stable performance under load

Specifications

BrandXPG
SeriesGAMMIX S11 Pro
ModelAGAMMIXS11P-1TT-C
Part NumberAGAMMIXS11P-1TT-C
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4, NVMe 1.3
ControllerSMI SM2262EN
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random ReadUp to 390,000 IOPS
4KB Random WriteUp to 380,000 IOPS
Terabytes Written (TBW)640TB
MTBF2,000,000 hours
HeatSinkwith HeatSink
Power Consumption (Idle)0.14W
Power Consumption (Active)0.33W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1500G
Height6.10mm
Width22.00mm
Depth80.00mm
Weight11.00g

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I pick the 1TB GAMMIX S11 Pro or a smaller capacity?

The 1TB model delivers up to 3500 MB/s sequential read and 3000 MB/s write with 640 TBW endurance, so it suits heavy gaming and rendering workloads better than lower-capacity variants.

What do the 3500/3000 MB/s figures mean once the drive is installed in my PC?

Those are peak sequential speeds over the PCIe 3.0 x4 link; real-world throughput depends on your motherboard's M.2 slot wiring, thermal headroom and the workload mix you run.

Does the PCIe 3.0 x4 NVMe 1.3 interface cap performance in practice?

The four-lane Gen 3 ceiling sits near 3500 MB/s read, so this drive already saturates the bus; a PCIe 4.0 platform would not raise its sequential numbers further.
