Aqua blue duplex multimode fibre cable with SC and ST connectors, 10m

Enfain

Enfain OM3 SC-ST Duplex Multimode Fibre Optic Cable 10m Aqua Blue

SKU CH-EEXA-MHE27

OM3 multimode duplex patch cable with SC and ST connectors, 10-metre aqua jacket, 3.0 mm diameter, 850 nm wavelength, .2 dB typical insertion loss, >38 dB return loss, rated for 1 Gb.

Length 10m

  • Low signal loss with 0.2 dB typical insertion loss
  • High return loss exceeding 38 dB for clean signals
  • Supports 10 Gbps over OM3 multimode fibre
  • Durable 3.0 mm PVC jacket rated for 1000 mating cycles
  • Wide operating range from -20 °C to +60 °C

What this cable is and who needs it

This Enfain OM3 multimode fibre patch cord connects equipment with SC and ST connectors over ten metres. The aqua blue 3.0 mm PVC jacket protects duplex fibres rated for 1 Gbps, 10 Gbps and 40 Gbps links in switches, servers and data-centre racks.

Who it suits and who should look elsewhere

Installers who need SC-to-ST duplex links at 850 nm wavelength with insertion loss of 0.2 dB typical and 0.3 dB maximum will find the spec met. Buyers requiring single-mode fibre, LC or MTP connectors, longer reach or higher bandwidth than OM3 provides should choose a different cable type.

The spec that decides fit

The OM3 10-gigabit core operating at 850 nm with ceramic ferrules and a 330 mm bending radius determines whether this patch cord matches the link budget and physical routing of your installation.

Prednosti

  • Low signal loss with 0.2 dB typical insertion loss
  • High return loss exceeding 38 dB for clean signals
  • Supports 10 Gbps over OM3 multimode fibre
  • Durable 3.0 mm PVC jacket rated for 1000 mating cycles
  • Wide operating range from -20 °C to +60 °C

Špecifikácie

Pre tento produkt zatiaľ nie sú zverejnené žiadne špecifikácie.

Ďalšie verzie tohto modelu

Ďalších 5 v tomto rade

Rovnaký rad, iná pamäť, chladič alebo frekvencia — porovnajte pred rozhodnutím.

Otázky k tomuto produktu

What does the OM3 10-gigabit core mean for actual link speeds?

The OM3 core supports 1 Gb/s, 10 Gb/s and 40 Gb/s multimode links at 850 nm wavelength.

How do the SC and ST connectors limit the cable's practical use?

One end uses an SC duplex connector and the other an ST duplex connector, so it only fits ports with those exact interfaces.

What physical space is needed to route the 3.0 mm jacket without exceeding the bend limit?

The cable requires a minimum bend radius of 330 mm and an operating temperature range of -20 °C to +60 °C.
