Black rectangular 2U rack tower UPS with LCD panel and eight NEMA 5-20R outlets

CyberPower

CyberPower OR2200PFCRT2U UPS 2000VA 1320W 120V 8 Outlets 2U Rack Tower

SKU CH-8SPD-F5HCF MPN OR2200PFCRT2U

Delivers 2000 VA pure sine-wave power with AVR and eight NEMA 5-20R outlets in a 2U rack-tower chassis

  • Input Voltage Range90 - 140V
  • Input Frequency47 - 63 Hz
  • VA Rating2000 VA
  • Watts1320 Watts
  • Output Voltage120Vac +/- 5%
  • Outlets8

Options OR2200PFCRT2U

  • Pure sine wave output protects Active PFC power supplies
  • Automatic voltage regulation corrects fluctuations without battery use
  • 2000 VA 1320 Watt capacity supports critical loads
  • Eight NEMA 5-20R outlets connect multiple devices
  • Rotatable LCD panel shows runtime load and battery status

Capacity and Output

The OR2200PFCRT2U delivers 2000 VA and 1320 W of pure sine wave power with automatic voltage regulation. Its eight NEMA 5-20R receptacles support equipment using Active PFC power supplies without unexpected shutdowns during transfer. The rotatable LCD panel shows load level, runtime, battery status, input and output voltage, and wiring faults. Audible alarms signal on-battery, low-battery and overload conditions.

Suitable Environments

This UPS protects networking hardware, servers, workstations and telecom gear in rack or tower orientation. It is not intended for loads exceeding 1320 W, for installations requiring longer battery runtime than eight minutes at full load, or for sites without a NEMA 5-20P supply circuit. The 59.3 lb weight demands a sturdy rack or shelf.

Key Specification

The 1320 W output rating is the single figure that determines whether this unit can support your connected load. Verify that the total power draw of all attached devices stays at or below this value before purchase.

商品特色

  • Pure sine wave output protects Active PFC power supplies
  • Automatic voltage regulation corrects fluctuations without battery use
  • 2000 VA 1320 Watt capacity supports critical loads
  • Eight NEMA 5-20R outlets connect multiple devices
  • Rotatable LCD panel shows runtime load and battery status

商品規格

BrandCyberPower
ModelOR2200PFCRT2U
Input Voltage Range90 - 140V
Input Frequency47 - 63 Hz
VA Rating2000 VA
Watts1320 Watts
Output Voltage120Vac +/- 5%
Outlets8
Outlet TypeNEMA 5-20R
Battery TypeSealed Lead Acid
Battery Run TimeRuntime at Half Load: 20 minutes
Runtime at Full Load: 8 minutes
Battery Recharge Time8 Hour(s)
Battery ReplaceableBB Battery - HR9-12 or Yuasa Battery NPW45-12FR
AlarmsAudible Alarms: On battery, low battery, overload
Management SoftwarePowerPanel Business Edition
ApprovalsUL1778, cUL 107.3, FCC DOC Class B
Surge Energy Rating2060 Joules
FeaturesMultifunction LCD Diagnostic Display:
Toggle Status Display includes: Current/Load Level, Runtime, Battery Level, AVR In Use, Battery In Use, Input Voltage, Output Voltage, Output Frequency, Overload, Wiring Fault, Silent Mode
Dimensions17.00" x 3.50" x 15.30"
Weight59.30 lbs.
出貨重量27.78 kg
包裝尺寸540 × 521 × 289 mm

其他版本

同系列還有 3 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

Should I choose the 2000VA model or a lower VA unit for my rack?

Select the 2000VA model when your connected load approaches 1320W; a lower VA unit would limit both runtime and the number of NEMA 5-20R outlets available.

What does the 1320W rating mean once the UPS is installed in my rack?

It is the maximum real power the inverter can deliver continuously; plan your server and networking gear so their combined draw stays below 1320W to avoid overload alarms.

What does the NEMA 5-20P input plug cap in practice?

The 5-20P plug requires a 20A branch circuit, so the UPS can draw up to 20A from the wall while supplying 120V ±5% to eight 5-20R outlets.
