Rectangular metal network switch with 16 front RJ45 ports and LED indicators

Netgear Inc.

Netgear Inc. GS316PP-100NAS 16-port Gigabit PoE+ network switch (183W)

SKU CH-A5B8-P88AQ MPN GS316PP-100NAS

16-port Gigabit unmanaged switch with 183W PoE+ budget, fanless metal case and desktop or rack mounting

  • FormatDesktop Wall Mountable Rack-mountable
  • StandardsIEEE 802.3 CSMA/CD 802.3az Energy Efficient Ethernet
  • Network MediaMedia Type Supported: Twisted Pair Ethernet Technology: Giga
  • Network Management TypeUnmanaged
  • Primary Ports16 x RJ45
  • Primary Port Speed10/100/1000Mbps

Model GS316PP

  • 16 PoE+ ports with 183W budget power cameras and phones
  • Fanless design runs silently in noise-sensitive spaces
  • Plug-and-play unmanaged setup needs no software or configuration
  • Non-blocking architecture delivers wire-speed throughput on every port
  • FlexPoE upgrades to 183W with optional power supply module

16-Port Gigabit PoE+ Switch

This unmanaged desktop switch provides sixteen RJ-45 ports running at 10/100/1000 Mbps with a 183 W PoE+ budget. It targets small offices and home networks that need to power wireless access points, IP cameras and VoIP phones over a single cable. The fanless metal chassis operates silently from 0 °C to 40 °C and meets NDAA compliance.

Build Integration — Power and Mounting

The unit accepts a 54 V, 3.7 A DC input rated at 200 W and can be upgraded to the full 183 W PoE budget with a separately purchased power supply module. Auto-MDI/MDIX removes the need for crossover cables while auto-negotiation sets the highest common speed on each link. Desktop, wall-mount and rack-mount options let the switch fit the available space without extra brackets.

PoE Automation and Indicators

Per-port LEDs show speed, link activity and PoE status while a dedicated PoE Max light warns when the total budget is reached. Netgear FlexPoE automatically balances power at the most granular level so each connected device receives only what it needs. The non-blocking architecture forwards jumbo frames up to 9216 bytes at wire speed with a 4 K MAC address table and 1 MB buffer.

商品特色

  • 16 PoE+ ports with 183W budget power cameras and phones
  • Fanless design runs silently in noise-sensitive spaces
  • Plug-and-play unmanaged setup needs no software or configuration
  • Non-blocking architecture delivers wire-speed throughput on every port
  • FlexPoE upgrades to 183W with optional power supply module

商品規格

BrandNETGEAR
Part NumberGS316PP-100NAS
FormatDesktop
Wall Mountable
Rack-mountable
StandardsIEEE 802.3 CSMA/CD
802.3az Energy Efficient Ethernet
Network MediaMedia Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
Network Management TypeUnmanaged
Primary Ports16 x RJ45
Primary Port Speed10/100/1000Mbps
MAC Address Table4K
Jumbo Frames9216 bytes
Buffer Memory1MB
PoEYes
QoSYes
Layer2
LEDsSpeed, Link/Activity (Left), PoE (Right), Power, PoE Max
PowerDC Input/Power In: 54V, 3.7A (200W PA)
CertificationNDAA Compliant:
Yes
Environmentally Friendly:
Yes
Energy Efficiency Compliance:
Energy-related Products Directive (ErP)
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
TemperatureOperating: 0° to 40°C (32° to 104°F)
Storage: -20° to 70°C (-4° to 158°F)
HumidityOperating: 90% maximum relative humidity (RH), non-condensing
Storage: 95% maximum relative humidity (RH), non-condensing
FeaturesAuto-MDI/MDIX eliminates the need for crossover cables
LED indicators for ease of use
Energy-efficient technology for power savings
Fanless design for silent operation
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
Non-blocking switching architecture for maximum throughput at wire speed
Plug-and-play; no setup required
Durable and rugged metal case
Desktop, wall-mountable or rack-mountable (based on specific model)
Ideal for small office and home networks
Standards-based technology ensures interoperability with any standards-bas
Package ContentsGS316PP Ethernet Switch
Power Adapter (localized to the country of sale)
Rubber Footpads for Desktop Installation
Wall Mount Kit and/or Rack Mount Kit
Installation Guide
出貨重量0.89 kg
包裝尺寸286 × 102 × 27 mm

其他版本

同系列還有 4 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

When does the 183 W PoE+ budget run out under sustained load?

The switch provides 183 W total for all 16 PoE+ ports; once combined draw reaches that limit, additional devices will not receive power.

How much heat or noise appears when the switch runs all day?

Fanless design gives silent operation; operating temperature range is 0 °C to 40 °C with 90 % maximum relative humidity, non-condensing.

What must I already own to power the switch itself?

A 54 V, 3.7 A DC source (the included 200 W power adapter) is required for the switch to operate.
