NShi desktop server chassis with Mean Well 600W power supply unit

NShi

NShi Server Chassis with Mean Well HRP-600-7.5 7.5V 80A 600W Power Supply

SKU CH-YA09-FRZQE

A desktop server chassis supplied with a 7.5V 80A 600W power supply featuring active PFC and full-load burn-in testing

  • Chassis TypeDesktop
  • Active PFC improves power efficiency
  • Constant current limiting protects against overload
  • Remote sense compensates for voltage drop
  • 100 % full load burn-in test validates reliability
  • 5 years warranty backs long-term operation

Server chassis with 7.5V 80A power supply

This desktop server chassis includes a Mean Well HRP-600-7.5 single-output unit rated at 7.5V and 80A for 600W continuous power. It suits builders assembling compact rack or tower systems that need a regulated low-voltage rail. The integrated supply simplifies wiring by removing the need for a separate ATX brick. Buyers who need multiple voltage rails or higher wattage should look elsewhere.

Active PFC and forced-air cooling

The built-in supply uses active PFC and a constant-current limiting circuit to maintain stable output under load. A DC fan provides forced-air cooling while protections cover short circuit, overload, over voltage and over temperature. No-load draw stays below 0.75W and the unit withstands a 300VAC surge for five seconds. Remote sense and DC OK signal lines allow external monitoring.

1U low-profile desktop form factor

The chassis adopts a 1U low-profile desktop layout that fits standard shallow racks or shelf mounts. Universal AC input accepts full-range mains without a voltage selector. Remote ON/OFF control and a 5V standby output let the host manage power state. Current sharing is available on 24V, 36V and 48V variants but not on this 7.5V model. Ensure your backplane and load cabling match the single 7.5V rail.

商品特色

  • Active PFC improves power efficiency
  • Constant current limiting protects against overload
  • Remote sense compensates for voltage drop
  • 100 % full load burn-in test validates reliability
  • 5 years warranty backs long-term operation

商品規格

Chassis TypeDesktop

商品問答

How do I install the HRP-600-7.5 power supply into the desktop chassis, and what connection step is often missed?

Mount the 1U low-profile unit in the chassis bay, secure it with screws, connect the AC input to a universal full-range source, and attach the DC output cables; the step often missed is wiring the remote sense terminals to the load for accurate voltage regulation.

What maintenance will the power supply need over its service life?

The built-in DC fan draws dust into the enclosure; periodically vacuum the intake vents and verify the DC OK signal remains active, and after several years consider replacing the fan assembly if airflow drops.

Which limit appears first when the supply runs continuously at full load?

The constant current limiting circuit engages at 80 A, capping output at 600 W; sustained operation at this level will trigger the over-temperature protection before any other limit is reached.
