Brass 90-degree rotary elbow fitting with 20mm extension, male and female G 1/4 threads

PrimoChill

PrimoChill 90 Degree SX Rotary 20mm Extension Elbow Fitting diy cooling

SKU CH-TTDK-XNZ5S

A 90-degree rotary elbow with a 20mm extension redirects tubing runs and provides clearance for tight water-cooling loops

  • TypeFittings

Option Yellow

顯示另外 9 款選項

被劃上刪除線的選項確實存在，但本站並無供貨。

  • Rotary joint lets you aim connections 90 degrees freely
  • 20 mm extension adds clearance around tight components
  • Male and female G 1/4 threads fit standard water-cooling loops
  • Coated brass construction resists corrosion in liquid systems
  • Pre-installed O-ring on male side seals without extra parts

Loop routing fitting for custom water cooling

The PrimoChill Male to Female G 1/4in. 90 Degree SX Rotary 20mm Extension Elbow Fitting redirects tubing runs away from components at unconventional angles. The rotary function lets you aim the connection in any desired direction 90 degrees from the mount. A 20mm extension provides added clearance when other parts are in the way or extra height is needed. It suits builders who want a compact right-angle adapter with rotational freedom.

Sustained loop behaviour

The coated brass construction resists corrosion during continuous coolant circulation. The installed O-ring on the male threaded side maintains a seal under steady system pressure. Rotary joints can, on rare occasions, dislodge after being moved around, which may disengage seals. If this occurs, removing the fitting, pressing in on the joints and rotating them typically restores the seal. Testing for leaks after any adjustment is recommended.

Thermals noise and power

As a passive brass fitting, it adds no heat, noise or electrical draw to the loop. The 20mm extension and 90-degree elbow change only the physical routing of tubing. The rotary mechanism moves freely without requiring power. Users who need a fixed-angle elbow without rotational movement should consider a non-rotary alternative.

商品特色

  • Rotary joint lets you aim connections 90 degrees freely
  • 20 mm extension adds clearance around tight components
  • Male and female G 1/4 threads fit standard water-cooling loops
  • Coated brass construction resists corrosion in liquid systems
  • Pre-installed O-ring on male side seals without extra parts

商品規格

TypeFittings

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

Does the 20mm extension on the rotary elbow add any pump noise or heat?

The fitting is a passive brass component with no moving parts, so it adds no pump noise and generates no heat during continuous operation.

Which G 1/4in ports must my loop already provide for this male-to-female elbow to thread in?

You need one female G 1/4in port for the male thread and one male G 1/4in port or component for the female thread to accept.

Will the coated brass rotary joint react with nickel-plated blocks or radiators I keep in the loop?

Coated brass is compatible with standard nickel-plated copper and brass components when used with proper coolant and corrosion inhibitors.
