Rectangular E3.S enterprise SSD with silver metal casing and edge connector visible

Solidigm

Solidigm SB5PHA7X076T001 enterprise SSD 7.68TB E3.S 7.5mm PCIe 5.0

SKU CH-3MW5-7TA8Z MPN SB5PHA7X076T001

E3.S 7.5mm enterprise SSD with 7.68TB capacity, PCIe 5.0 interface, up to 14500 MBps read and 10000 MBps write

  • Form FactorE3.S 7.5mm
  • Capacity7.68TB
  • Memory Components176L TLC 3D NAND
  • InterfacePCI-Express 5.0
  • Max Sequential ReadUp to 14500 MBps
  • Max Sequential WriteUp to 10000 MBps

Option 7.68TB E3.S

Voir les 20 autres configurations
  • Handles massive datasets with 7.68TB capacity
  • Accelerates heavy workloads through PCIe 5.0 speeds
  • Sustains mixed traffic at 3000000 random read IOPS
  • Fits dense servers in E3.S 7.5mm form factor
  • Delivers 14 PBW endurance for write-intensive apps

7.68TB E3.S SSD for dense servers

This 7.68TB Solidigm D7-PS1010 drive fits the E3.S 7.5mm form factor and connects through a PCIe 5.0 x4 link. It targets data-centre operators who need high-capacity flash in a compact, hot-pluggable tray. The 176L TLC 3D NAND delivers 1 DWPD endurance rated at 14 PBW.

PCIe 5.0 x4 ceiling and thermal envelope

The drive reaches 14500 MBps sequential read and 10000 MBps sequential write within the four-lane PCIe 5.0 interface. Random performance peaks at 3000000 read IOPS and 400000 write IOPS. Active power draws 23W and the operating range stops at 77°C, so chassis airflow must dissipate that heat without exceeding the limit.

E3.S slot, power budget and cooling clearance

Verify the server has an E3.S 7.5mm bay with a PCIe 5.0 x4 electrical connection and a backplane that can supply 23W per drive. Confirm the cooling design keeps the drive at or below 77°C under sustained load. The 110g weight and 1000 G shock rating suit standard enterprise trays, but the bay must accept the 7.5mm thickness.

Points forts

  • Handles massive datasets with 7.68TB capacity
  • Accelerates heavy workloads through PCIe 5.0 speeds
  • Sustains mixed traffic at 3000000 random read IOPS
  • Fits dense servers in E3.S 7.5mm form factor
  • Delivers 14 PBW endurance for write-intensive apps

Caractéristiques

BrandSolidigm
ModelD7-PS1010
Part NumberSB5PHA7X076T001
Form FactorE3.S 7.5mm
Capacity7.68TB
Memory Components176L TLC 3D NAND
InterfacePCI-Express 5.0
Max Sequential ReadUp to 14500 MBps
Max Sequential WriteUp to 10000 MBps
4KB Random Read3000000 IOPS (4K Blocks)
4KB Random Write400000 IOPS (4K Blocks)
Endurance1 DWPD / 14 PBW
MTBF2,500,000 hours
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C to 77°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight110g +/- 10g
Poids d’expédition0.17 kg
Dimensions du colis140 × 110 × 17 mm

Autres versions de ce modèle

5 de plus dans cette gamme

Même famille, mémoire, ventirad ou fréquence différents — comparez avant de vous décider.

Questions sur cet article

Which capacity should I choose for a read-intensive server workload?

This model is offered in a single 7.68TB capacity with 1 DWPD endurance, rated for 14 PBW total writes.

What does the 14500 MBps sequential read figure mean once the drive is installed in a server?

It represents the maximum sustained read throughput under ideal PCIe 5.0 conditions; actual throughput depends on workload, queue depth and system cooling.

What does the PCIe 5.0 interface cap in practice for this E3.S drive?

The drive uses a PCIe 5.0 x4 link, so peak bandwidth is limited by the four-lane electrical interface and the 23W active power envelope.
