Black dual-fan graphics card with silver backplate

ASUS

ASUS PRIME GeForce RTX 5060 Ti 16GB GDDR7 graphics card

SKU CH-FNXB-9BFHA

16GB GDDR7 memory on a 128-bit bus with 4608 CUDA cores, PCIe 5.0 x8, DLSS 4.0 and three DisplayPort 2.1b plus HDMI 2.1b outputs

  • InterfacePCI Express 5.0 x8
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5060 Ti
  • ArchitectureBlackwell
  • CUDA Cores4608

model PRIME

  • 16 GB GDDR7 memory delivers 28 Gbps bandwidth for high-resolution textures
  • 4608 CUDA cores accelerate rendering and compute workloads
  • DLSS 4.0 upscaling boosts frame rates with AI-generated frames
  • PCI Express 5.0 x8 interface provides high-throughput data transfer
  • HDMI 2.1b and three DisplayPort 2.1b outputs support 7680 x 4320 resolution

ASUS PRIME RTX 5060 Ti 16GB

This ASUS PRIME graphics card uses the NVIDIA GeForce RTX 5060 Ti GPU built on the Blackwell architecture. It delivers 4608 CUDA cores and 16GB of GDDR7 memory running at 28 Gbps across a 128-bit interface. The board targets gamers and creators who want 1440p performance with DLSS 4.0 upscaling and frame generation. DirectX 12 Ultimate and OpenGL 4.6 support cover modern APIs.

PCI Express 5.0 x8 build fit

The card installs in a PCI Express 5.0 x8 slot and works in x16 slots at x8 electrical width. It provides one HDMI 2.1b port and three DisplayPort 2.1b outputs for up to four monitors at 7680 x 4320 resolution. The 128-bit memory bus keeps the PCB compact, helping the card fit in smaller cases. No legacy video connectors are included.

Upgrade from 12GB or 8GB models

Moving from a 12GB or 8GB card adds 16GB of VRAM, which helps with high-resolution textures and large creative workloads. The jump is worth it when your current GPU hits memory limits in games or rendering at 1440p and 4K. GDDR7 bandwidth and DLSS 4.0 improve frame rates without raising the memory bus width. The Blackwell architecture also brings newer ray-tracing and AI cores.

Highlights

  • 16 GB GDDR7 memory delivers 28 Gbps bandwidth for high-resolution textures
  • 4608 CUDA cores accelerate rendering and compute workloads
  • DLSS 4.0 upscaling boosts frame rates with AI-generated frames
  • PCI Express 5.0 x8 interface provides high-throughput data transfer
  • HDMI 2.1b and three DisplayPort 2.1b outputs support 7680 x 4320 resolution

Specifications

BrandASUS
SeriesPRIME
ModelPRIME-RTX5060TI-16G
InterfacePCI Express 5.0 x8
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5060 Ti
ArchitectureBlackwell
CUDA Cores4608
Effective Memory Clock28 Gbps
Memory Size16GB
Memory Interface128-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
ColorBlack
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
Virtual Reality ReadyYes
CoolerTriple Fans
Recommended PSU Wattage550W
Power Connector8-Pin
Features• AI Performance: 758 AI TOPS
• Powered by the NVIDIA Blackwell architecture and DLSS 4
• SFF-Ready Enthusiast GeForce Card
• Axial-tech fans feature a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
• 2.5-slot design allows for greater build compatibility while maintaining cooling performance
• Dual-ball fan bearings last up to twice as long as standard sleeve bearings
• 0dB technology lets you enjoy light gaming in relative silence
• Dual BIOS switch lets you toggle between Quiet and Performance BIOS profiles
• Auto-Extreme man
Form FactorATX
Max GPU Length304 mm
Card Dimensions (L x H)304 x 120 x 50 mm
11.96 x 4.72 x 1.97 inch
Slot Width2.5 Slots

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What is the thermal limit of the 16GB GDDR7 memory under sustained load?

The 16GB GDDR7 memory runs on a 128-bit interface at 28 Gbps effective clock, with the Blackwell architecture managing thermals through the dual-fan PRIME cooler design.

How loud does the dual-fan cooler get during all-day rendering?

The ASUS PRIME dual-fan cooler keeps the GeForce RTX 5060 Ti quiet during extended sessions, with the 4608 CUDA cores and GDDR7 memory staying within thermal targets under continuous workloads.

Does my motherboard need a PCI Express 5.0 x8 slot for this card?

The card uses a PCI Express 5.0 x8 interface and fits any motherboard with a compatible x16 slot, while also requiring a power supply with sufficient 12VHPWR or 8-pin connectors for the GPU.
