Tower server chassis with eight 3.5-inch hot-plug drive bays and DVD drive

DELL

DELL PowerEdge T320 Tower Server E5-2420 1.9GHz 64GB DDR3 H310 2x 495W

SKU CH-C73V-Y2T2B MPN E5-2420

Tower server with a six-core Xeon E5-2420 at 1.9 GHz, 64 GB DDR3, H310 RAID controller supporting RAID 0/1/5/10/50/60, and eight 3.5-inch hot-plug bays

  • TypeTower
  • Redundant Hot-swap PowerNo
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C600
  • Installed Memory Size64GB

Installed Memory Size 64GB

CPU Model E5-2420

  • Six-core Xeon at 1.9 GHz handles parallel workloads
  • 64 GB DDR3 memory supports virtualisation density
  • H310 RAID controller enables RAID 0/1/5/10/50/60
  • Dual 495 W supplies keep the system running
  • Eight hot-plug 3.5-inch bays simplify storage expansion

Tower Server for Single-Socket Workloads

The Dell PowerEdge T320 is a tower server built around a single Intel Xeon E5-2420 six-core processor running at 1.9 GHz with 64 GB of DDR3 memory already installed. It includes a PERC H310 RAID controller supporting RAID 0, 1, 5, 10, 50 and 60 across up to eight 3.5-inch hot-plug drive bays, and ships with two 495 W redundant power supplies and a DVD-ROM drive.

Suits Small Business and Remote Office Roles

This system fits organisations that need a quiet tower form factor for file, print, or lightweight virtualisation tasks where a single processor and DDR3 memory are sufficient. It is not suited for buyers who need more than one physical processor, GPU-accelerated compute, or memory capacity beyond the 64 GB installed limit of this configuration.

Max Memory Locked at 64 GB DDR3

The motherboard provides six DIMM slots but the specification caps total memory at 64 GB of DDR3, so no further expansion is possible beyond what is already populated. Buyers anticipating growth to 192 GB or requiring newer memory generations should evaluate a different platform.

Highlights

  • Six-core Xeon at 1.9 GHz handles parallel workloads
  • 64 GB DDR3 memory supports virtualisation density
  • H310 RAID controller enables RAID 0/1/5/10/50/60
  • Dual 495 W supplies keep the system running
  • Eight hot-plug 3.5-inch bays simplify storage expansion

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge T320
TypeTower
Redundant Hot-swap PowerNo
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C600
Installed Memory Size64GB
Memory TypeDDR3
Max Memory Capacity64GB
Memory Features6 DIMM slots. (2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots6
Storage ControllerDell Perc H310 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementBasic management (default), iDRAC7 with Lifecycle Controller, iDRAC7 Express (upgrade option) or iDRAC7 Enterprise
(upgrade option), 8GB or 16GB vFlash media (upgrade options)
LAN Ports2 x Ports
Expansion Slots5 PCIe slots: 1 x16 with x16 bandwidth, 3.0, full-length, fullheight; 1 x8 with x4 bandwidth, 3.0, half-length, fullheight1 x8 with x4 bandwidth, 2.0, half-length, full-height; 1 x8 with x4 bandwidth, 3.0, full-length, full-height; 1 x8 with x1 bandwidth, 2.0, full-length, full-height
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power do the dual 495W supplies draw when the server runs continuously?

Each supply is rated at 495W. Actual draw depends on workload and the single Xeon E5-2420 at 1.9GHz with 64GB DDR3 installed.

Which drives and trays must I supply to use the eight 3.5-inch hot-plug bays?

The chassis accepts 3.5-inch SATA or SAS drives. No drives or trays are included, so you must provide both.

Will a PCIe 3.0 card in the x16 slot work at full bandwidth with the Xeon E5-2420?

The x16 slot is PCIe 3.0 full-length, full-height. The E5-2420 supports PCIe 3.0, so the slot can run at x16 bandwidth.
