White Micro-ATX case with tempered glass side panel and detachable carrying handle on top

JONSPLUS

JONSPLUS Z20 White Micro-ATX PC Case with Carrying Handle

SKU CH-TZJD-HBMZC

A compact 20 L Micro-ATX case with a detachable handle, tempered glass panels, magnetic dust filters and room for a 363 mm GPU, 240 mm top radiator and 160 mm CPU cooler

  • TypeMicro ATX / Mini-ITX
  • ColorWhite
  • Case MaterialSPCC steel plate, tempered glass
  • Dust FiltersYes
  • Internal 3.5" Drive Bays1
  • Internal 2.5" Drive Bays3

Options Z20 Pink/White

  • Carry the build anywhere with the detachable handle
  • Fit high-end parts in a compact 20 L chassis
  • Cool with a top-mounted 240 mm radiator up to 60 mm thick
  • Install long graphics cards up to 363 mm with the removable PCIe bracket
  • Choose air cooling up to 164 mm or water cooling with 160 mm clearance

Compact Micro-ATX Chassis

The JONSPLUS Z20 White is a 20-litre Micro-ATX and Mini-ITX case built from 2 mm SPCC steel and tempered glass. A detachable carrying handle makes it simple to move between desk setups or LAN events. Magnetic dust filters cover the major intake areas to keep internals clean.

Storage and Hardware Limits

One internal 3.5-inch bay and three 2.5-inch bays handle a modest drive stack. The case accepts graphics cards up to 363 mm long and power supplies up to 180 mm deep. CPU cooler clearance reaches 160 mm, with air coolers limited to 164 mm on Intel or 163 mm on AMD platforms.

Cooling Capacity and Noise Profile

A 240 mm radiator up to 60 mm thick fits in the top panel for liquid cooling. Fan mounts support two 120 mm or 140 mm units on top and bottom, plus a rear 120 mm or 92 mm fan. The perforated steel panels promote airflow while the magnetic filters reduce dust without adding noticeable restriction.

Highlights

  • Carry the build anywhere with the detachable handle
  • Fit high-end parts in a compact 20 L chassis
  • Cool with a top-mounted 240 mm radiator up to 60 mm thick
  • Install long graphics cards up to 363 mm with the removable PCIe bracket
  • Choose air cooling up to 164 mm or water cooling with 160 mm clearance

Specifications

BrandJONSPLUS
ModelZ20 WHITE
TypeMicro ATX / Mini-ITX
ColorWhite
Case MaterialSPCC steel plate, tempered glass
Dust FiltersYes
Internal 3.5" Drive Bays1
Internal 2.5" Drive Bays3
Expansion Slots4
Front PortsUSB 3.2 Gen 1 Type-A:1 USB 3.2 Gen 2 Type-C:1 HP & Micr Audio Port x1
Fan OptionsTop:2 x 120mm / 2 x 140mm Rear:1 x 120mm / 1 x 92mm Bottom:2 x 120mm / 2 x 140mm
Radiator OptionsCPU water cooling radiator: top, 240mm
Max GPU Length363 mm
Max CPU Cooler Height160 mm
Max PSU Length180 mm
Dimensions382x 198 x 335mm/15.04”x7.80”x13.19”
Weight5KGS/ 11.02LB
Package ContentCarrying Handle Combo Kit - Graphics Card Support Bracket Combo Kit ? 3.5-inch HDD Mounting Bracket - Dual 2.5-inch SSD Mounting Brackets, Chassis Rear Dust Filter ? SFX TO ATX Power Conversion Bracket - Screw Boxes/User's Guide

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will my existing ATX power supply fit in this Micro-ATX case?

The case accepts power supplies up to 180 mm long and includes an SFX-to-ATX conversion bracket so a standard ATX unit can be mounted.

How can I confirm the 240 mm radiator I plan to install is seated correctly?

The top panel supports a 240 mm AIO up to 60 mm thick; after mounting, verify the pump runs and coolant temperatures stabilise under load.

Does the box include everything needed to mount a 3.5-inch hard drive and a graphics card?

The package supplies a 3.5-inch HDD bracket, dual 2.5-inch SSD brackets and a graphics card support bracket; only the drives and card themselves are separate.
