Rectangular green micro-ATX board with silver PCIe and RAM slots, black I/O shield and M.2 heatsinks

MSI

MSI PRO B760M-P DDR4 Intel motherboard

SKU CH-J802-X7T2M MPN PRO B760M-P DDR4

Micro-ATX LGA 1700 board with four DDR4 slots, dual M.2 and PCIe 4.0 graphics support for 12th to 14th Gen Intel CPUs

  • CPU Socket TypeLGA 1700
  • CPU TypeSupports 12th / 13th Gen Intel Core Processors, Pentium Gold
  • ChipsetIntel B760
  • Number of Memory Slots4x288pin (DDR4)
  • Memory StandardDDR4 3200
  • Maximum Memory Supported128GB

Option PRO B760M-P DDR4

Struck-through versions exist but are not stocked here.

  • Supports 12th, 13th and 14th Gen Intel Core CPUs on LGA 1700 socket
  • Four DDR4 slots accept up to 128 GB at 3200 MT/s with Intel XMP 2.0
  • PCIe 4.0 x16 slot plus two M.2 sockets each capable of PCIe 4.0 x4 speeds
  • Rear I/O includes USB 3.2 Gen 2×2 Type-C and USB 3.2 Gen 2 Type-C ports
  • Reinforced PCIe Steel Armor protects heavy graphics cards from bending and EMI

Socket LGA 1700 DDR4 platform

The MSI PRO B760M-P DDR4 is a Micro ATX motherboard built around the Intel B760 chipset for 12th, 13th and 14th generation Core, Pentium Gold and Celeron processors. It provides four 288-pin slots supporting dual-channel DDR4 up to 3200 MT/s and a maximum capacity of 128 GB with Intel XMP 2.0 profiles.

Steel-armoured PCIe 4.0 x16 and dual M.2

A reinforced PCI Express 4.0 x16 slot protects heavier graphics cards from bending and EMI. Two M.2 sockets accept 2242, 2260 and 2280 devices; the first runs at PCIe 4.0 x4 from the CPU, the second at PCIe 4.0 x4 or SATA from the chipset. Four SATA 6 Gb/s ports remain, though the fifth SATA port is disabled when an M.2 SATA drive occupies the second slot. Rear I/O includes D-Sub, DisplayPort, HDMI, USB 3.2 Gen 2 Type-C, USB 3.2 Gen 2x2 Type-C and four USB 2.0 ports driven by a Realtek ALC897 8-channel audio codec.

BIOS update and power-phase check

Some 14th generation CPUs require a BIOS update before booting, so verify the board revision or prepare a supported processor for the flash. Confirm your CPU cooler mounting holes match the LGA 1700 pattern and that your power supply delivers an 8-pin EPS connector for the VRM. Ensure the Micro ATX form factor fits your case and that front-panel headers align with the board layout.

Highlights

  • Supports 12th, 13th and 14th Gen Intel Core CPUs on LGA 1700 socket
  • Four DDR4 slots accept up to 128 GB at 3200 MT/s with Intel XMP 2.0
  • PCIe 4.0 x16 slot plus two M.2 sockets each capable of PCIe 4.0 x4 speeds
  • Rear I/O includes USB 3.2 Gen 2×2 Type-C and USB 3.2 Gen 2 Type-C ports
  • Reinforced PCIe Steel Armor protects heavy graphics cards from bending and EMI

Specifications

BrandMSI
ModelPRO B760M-P DDR4
CPU Socket TypeLGA 1700
CPU TypeSupports 12th / 13th Gen Intel Core Processors, Pentium Gold and Celeron Processors
ChipsetIntel B760
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 3200
Maximum Memory Supported128GB
Channel SupportedDual Channel
Memory Performance ProfileIntel XMP 2.0
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express x161 x PCI Express x16
PCI Express x12 x PCI Express x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
Audio ChipsetRealtek ALC897
Audio Channels8 Channels
Back I/O Ports1 x D-Sub / 1 x DisplayPort / 1 x HDMI / 1 x USB 3.2 Gen 2 Type-C / 1 x USB 3.2 Gen 2x2 Type-C / 4 x USB 2.0/1.1
Form FactorMicro ATX
Shipping weight2.04 kg
Package size330 × 279 × 102 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What speed does the PCIe 4.0 x16 slot cap at for a graphics card?

The single PCIe 4.0 x16 slot runs at up to PCIe 4.0 x16 speeds, giving a graphics card full Gen 4 bandwidth.

What case size and mounting holes does this Micro ATX board need?

It fits any chassis with Micro ATX or ATX mounting points and standard I/O shield cutout.

Which M.2 slot should I use first for a PCIe 4.0 SSD, and what size screws do the standoffs take?

Use M.2_1 for a PCIe 4.0 x4 drive; it accepts 2280, 2260 and 2242 lengths with standard M.2 mounting screws.
