Copper coloured 90 degree rotary elbow fitting with 20mm extension

PrimoChill

PrimoChill G1/4 90° Rotary 20mm Extension Elbow Candy Copper

SKU CH-SMSC-7D3RF

A 90-degree rotary G1/4 extension elbow with 20mm clearance and 360-degree adjustment for custom loop routing

  • TypeFittings

Option Candy Copper

Show 9 more configurations

Struck-through versions exist but are not stocked here.

  • 360° rotary lets you aim the port in any direction
  • 90° elbow redirects tubing runs around tight spaces
  • 20 mm extension adds clearance for crowded builds
  • G1/4 male-to-female threads fit standard water-cooling loops
  • Brass body with Candy Copper powder coat resists corrosion

Precision Loop Routing

The PrimoChill G1/4 90° rotary extension elbow lets builders redirect hard tubing runs at a right angle while adding 20mm of clearance. Its 360-degree swivel base allows the outlet to face any direction without stressing adjacent fittings. The Candy Copper SX powder coat resists wear and matches themed builds. It suits custom loops where space around GPU blocks or radiator ports is tight.

Verify Thread Compatibility

Confirm every component in your loop uses G1/4 threads before ordering. The male end screws into a female port with a 5mm thread depth; the female end accepts a standard male fitting. Measure available height — installed base height is 43mm total — so the elbow clears nearby components. Ensure your tubing OD matches the compression fittings you will pair with this adapter.

Integrates With Standard Fittings

The brass body threads directly into existing G1/4 ports on blocks, radiators or reservoirs. The rotary joint frees you from aligning fixed elbows during assembly. The 20mm extension lifts the connection away from crowded motherboard heatsinks or backplates. It adds no proprietary parts — just standard compression fittings and tubing complete the run.

Highlights

  • 360° rotary lets you aim the port in any direction
  • 90° elbow redirects tubing runs around tight spaces
  • 20 mm extension adds clearance for crowded builds
  • G1/4 male-to-female threads fit standard water-cooling loops
  • Brass body with Candy Copper powder coat resists corrosion

Specifications

TypeFittings

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the Candy Copper elbow come with any extra O-rings or tools, or is it just the single fitting?

The package contains only one male-to-female G1/4 90° rotary 20 mm extension elbow fitting; no additional O-rings or tools are included.

I only see one Candy Copper version listed — are there different lengths or angles to choose from?

This specific fitting is a fixed 20 mm extension with a 90° bend; other lengths or angles would be separate products.

The spec says 43 mm total height and 20 mm installed base height — how much space will it actually add above my block?

Once screwed in, the elbow sits 20 mm above the port, while the overall piece measures 43 mm tall including the male thread.
