PrimoChill Candy Purple 90 degree rotary G1/4 fitting 20mm extension

PrimoChill

PrimoChill Male to Female G1/4 90° Rotary 20mm Extension Elbow Fitting Candy Purple DIY Cooling

SKU CH-758K-A5ZCG

G1/4 rotary 90° elbow with 20 mm extension and 360° swivel for tight-loop routing

  • TypeFittings

Option Candy Purple

Show 9 more configurations

Struck-through versions exist but are not stocked here.

  • Rotary joint lets you aim tubing 360° for tight builds
  • 90° elbow redirects flow instantly around cramped components
  • 20 mm extension clears obstacles without extra fittings
  • 43 mm total height keeps loop profile low
  • SX powder-coated Candy Purple finish resists corrosion and matches theme

PrimoChill G1/4 90° Rotary Extension Fitting

This Candy Purple elbow fitting connects a male G1/4 thread to a female G1/4 port at a right angle. It is built for custom liquid-cooling loops where space is tight and tubing must turn sharply. The 360-degree rotary base lets you orient the outlet in any direction before tightening. The 20 mm extension adds clearance around crowded components.

20 mm extension and 90° turn for tight routing

The 20 mm installed base height moves the connection point away from the block or radiator port. This clears VRM heatsinks, motherboard shrouds or adjacent fittings that would otherwise block a straight coupler. The 90-degree bend handles sharp direction changes without kinking tubing. Total height reaches 43 mm, so very shallow builds may still find it too tall.

Brass body with powder-coated finish

The brass construction resists corrosion in mixed-metal loops when proper coolant is used. A durable SX powder coat provides the Candy Purple colour and protects the surface from minor scratches during installation. The rotary joint uses an internal O-ring seal that must be lubricated before assembly. No additional adapters or tools are included in the package.

Highlights

  • Rotary joint lets you aim tubing 360° for tight builds
  • 90° elbow redirects flow instantly around cramped components
  • 20 mm extension clears obstacles without extra fittings
  • 43 mm total height keeps loop profile low
  • SX powder-coated Candy Purple finish resists corrosion and matches theme

Specifications

TypeFittings

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 20 mm extension clear tall VRM heatsinks on an older motherboard?

The 20 mm installed base height and 43 mm total height move the tubing run further from the board, giving extra clearance for tall heatsinks.

How can I verify the 360° rotary joint moves freely after installation?

With the loop depressurised, gently rotate the female end through a full 360° turn; it should move smoothly without binding.

Does the box include any extra O-rings or compression rings for G1/4 ports?

The package contains only the single Candy Purple elbow fitting; sealing rings for G1/4 threads must be sourced separately.
