Rectangular 2.5 inch silver metal drive with label and SATA connectors

SAMSUNG

SAMSUNG 860 EVO 1TB 2.5" SATA internal SSD MZ-76E1T0B/AM

SKU CH-ME45-2XWHN MPN MZ-76E1T0B/AM

A 2.5" SATA internal SSD with 1TB capacity, V-NAND 3-bit MLC, up to 550 MBps read and 520 MBps write, plus 1GB DDR4 cache

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form Factor2.5"
  • Capacity1TB
  • Memory ComponentsV-NAND 3-bit MLC
  • InterfaceSATA III

Options 1TB

  • Fast boot and load times with sequential read up to 550 MBps
  • Responsive multitasking from random read up to 98,000 IOPS at QD32
  • Smooth write performance with sequential write up to 520 MBps
  • Reliable storage backed by 1,500,000 hours MTBF
  • Low power draw averaging 3.0W active consumption

1TB SATA III SSD for consumer builds

The Samsung 860 EVO delivers 1TB of storage in a 2.5 inch form factor using V-NAND 3-bit MLC memory. It connects through a standard SATA III interface and is managed by a Samsung MJX controller with 1GB Low Power DDR4 cache. Designed for consumer workloads, it suits desktops and laptops that need reliable solid-state capacity.

Fits 2.5 inch bays with SATA power and data

Installation requires a 2.5 inch drive bay, a SATA data cable and a SATA power connector from the supply. The 7.00mm height matches typical laptop and desktop caddies so no adapter is needed. Because it uses the SATA bus it frees M.2 slots for other devices while still providing solid-state speed for operating systems and applications.

Low power draw and quiet operation

Active power averages 3.0W with a 4.0W burst maximum, keeping heat output modest inside the chassis. The drive operates from 0°C to +70°C and carries a 1,500,000 hour MTBF rating. With no moving parts it runs silently and withstands 1,500G shock, making it stable in mobile and desktop environments alike.

Highlights

  • Fast boot and load times with sequential read up to 550 MBps
  • Responsive multitasking from random read up to 98,000 IOPS at QD32
  • Smooth write performance with sequential write up to 520 MBps
  • Reliable storage backed by 1,500,000 hours MTBF
  • Low power draw averaging 3.0W active consumption

Specifications

BrandSAMSUNG
Series860 EVO Series
ModelMZ-76E1T0B/AM
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form Factor2.5"
Capacity1TB
Memory ComponentsV-NAND 3-bit MLC
InterfaceSATA III
ControllerSamsung MJX
CacheSamsung 1GB Low Power DDR4 SDRAM
Max Sequential ReadUp to 550 MBps
Max Sequential WriteUp to 520 MBps
4KB Random ReadRandom (QD1): Up to 10,000 IOPS
Random (QD32): Up to 98,000 IOPS
4KB Random WriteRandom (QD1): Up to 42,000 IOPS
Random (QD32): Up to 90,000 IOPS
MTBF1,500,000 hours
Power Consumption (Active)Average: 3.0W
Maximum: 4.0W (Burst mode)
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,500G & 0.5 ms (Half sine)
Height7.00mm
Width70.00mm
Depth100.00mm
Weight86.18g
Shipping weight0.07 kg
Package size145 × 99 × 20 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

At what temperature does the 860 EVO 1TB throttle during sustained heavy writes?

The drive is rated for continuous operation up to 70 °C; sustained workloads that push the controller to this limit will trigger thermal throttling to protect the NAND and MJX controller.

How much heat and noise should I expect from the 860 EVO 1TB when it runs all day in a desktop?

With no moving parts the SSD is silent; average active power is 3.0 W and peaks at 4.0 W, so heat output is low and easily handled by normal case airflow.

What existing hardware must my system have for this 2.5" SATA III 1TB drive to work?

A free 2.5" drive bay or bracket, a SATA data cable and a SATA power connector from the power supply are required; the drive uses the standard SATA III interface.
