Green rectangular M.2 2280 SSD circuit board with gold edge connector and black controller chip visible

SanDisk

SanDisk Optimus 5100 2TB M.2 2280 internal SSD SDSP51200TAN-000E0

SKU CH-B51A-A9RS8 MPN SDSP51200TAN-000E0

2TB M.2 2280 internal SSD with PCI-Express 4.0 x4 NVMe interface delivering up to 7100 MBps read and 6700 MBps write speeds

  • Device TypeInternal Solid State Drive (SSD)
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory ComponentsQLC 3D CBA NAND
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe

Capacity 2TB

  • Fast system responsiveness with up to 7100 MBps sequential read
  • Quick file saves and transfers at up to 6700 MBps sequential write
  • Smooth multitasking from up to 1,000,000 IOPS random read
  • Heavy workload endurance rated for 900TB written
  • Long-term reliability with 1,750,000 hours MTBF

SanDisk Optimus 5100 2TB M.2 2280

The SanDisk Optimus 5100 is a 2TB internal solid state drive built on the M.2 2280 form factor. It uses a PCI-Express 4.0 x4 interface with the NVMe protocol. The drive employs QLC 3D CBA NAND memory components. It is designed for desktop and laptop users who need high-capacity storage for operating systems, applications and large media libraries.

Sustained write behaviour on QLC 3D CBA NAND

The drive delivers a maximum sequential write speed of up to 6700 MBps and a 4KB random write rating of up to 1,300,000 IOPS. Under heavy continuous workloads the QLC architecture writes directly to the flash after any SLC cache is filled. The 900TB terabytes written rating and 1,750,000 hours MTBF indicate the endurance ceiling for long-term write-heavy usage scenarios.

Thermals noise and power draw in normal use

The drive operates without a heatsink and has an idle power draw of 4 mW. Average active power consumption is 4.1W for both read and write operations. The operating temperature range spans 0°C to 85°C. With no moving parts the drive produces no acoustic noise during operation.

Highlights

  • Fast system responsiveness with up to 7100 MBps sequential read
  • Quick file saves and transfers at up to 6700 MBps sequential write
  • Smooth multitasking from up to 1,000,000 IOPS random read
  • Heavy workload endurance rated for 900TB written
  • Long-term reliability with 1,750,000 hours MTBF

Specifications

BrandSanDisk
SeriesOptimus 5100
ModelSDSP51200TAN-000E0
Device TypeInternal Solid State Drive (SSD)
Form FactorM.2 2280
Capacity2TB
Memory ComponentsQLC 3D CBA NAND
InterfacePCI-Express 4.0 x4
ProtocolNVMe
Max Sequential ReadUp to 7100 MBps
Max Sequential WriteUp to 6700 MBps
4KB Random ReadUp to 1,000,000 IOPS
4KB Random WriteUp to 1,300,000 IOPS
Terabytes Written (TBW)900TB
MTBF1,750,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)4 mW
Power Consumption (Active)Average Active Power Read: 4.1W
Average Active Power Write: 4.1W
Operating Temperature0°C ~ +85°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1,500G @ 0.5 ms half-sine
Max Vibration ResistanceOperating Vibration: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating Vibration: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22mm
Depth80mm
Weight5.7g
Shipping weight0.05 kg
Package size127 × 102 × 23 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power does the Optimus 5100 draw during sustained all-day workloads?

Average active power is 4.1W for both read and write operations, while idle power drops to 4 mW.

Does my motherboard need a PCIe 4.0 x4 M.2 slot to run the Optimus 5100?

The drive uses a PCI-Express 4.0 x4 interface with NVMe protocol and requires an M.2 2280 key-M slot.

Will the Optimus 5100 fit and work in a laptop that only has a PCIe 3.0 M.2 slot?

It fits the standard M.2 2280 form factor at 2.38 mm height and will operate at PCIe 3.0 speeds in a 3.0 slot.
