Green circuit board M.2 2280 SSD with black chips, no heatsink

SanDisk

SanDisk Optimus 5100 M.2 2280 500GB PCI-Express 4.0 x4 internal SSD SDSP51500GAN-000E0

SKU CH-NNZ2-3TZK9 MPN SDSP51500GAN-000E0

An M.2 2280 500GB drive using QLC 3D CBA NAND over PCI-Express 4.0 x4 with NVMe, reaching 6600 MBps read and 5600 MBps write, rated for 300TB written and 1,750,000 hours MTBF

  • Device TypeInternal Solid State Drive (SSD)
  • Form FactorM.2 2280
  • Capacity500GB
  • Memory ComponentsQLC 3D CBA NAND
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe

Capacity 500GB

  • Fast boot and load times from up to 6600 MBps sequential read
  • Quick file saves and installs with up to 5600 MBps sequential write
  • Responsive multitasking backed by up to 1,100,000 IOPS random write
  • Long service life supported by 300TB written endurance
  • Cool, low-power operation at 4 mW idle consumption

SanDisk Optimus 5100 500GB PCIe 4.0 x4 NVMe SSD

The SanDisk Optimus 5100 is a 500GB internal solid state drive using QLC 3D CBA NAND. It connects via an M.2 2280 form factor with a PCI-Express 4.0 x4 interface and NVMe protocol. Sequential reads reach up to 6600 MBps and writes up to 5600 MBps. Random read performance hits 660,000 IOPS while random write reaches 1,100,000 IOPS.

Check motherboard M.2 slot key

Verify the board provides an M.2 2280 slot wired for PCI-Express 4.0 x4 and NVMe signalling. Confirm the slot accepts single-sided modules 2.38mm high and 22mm wide. Ensure the system BIOS supports NVMe boot if the drive will hold the operating system. No heatsink is included so assess airflow around the slot.

Thermals noise and power in normal use

The drive operates between 0°C and 85°C with no moving parts for silent running. Idle power draw is 4 mW while active read and write average 3.8W each. Endurance is rated at 300TB written and MTBF at 1,750,000 hours. Shock resistance reaches 1,500G at 0.5 ms and vibration tolerance covers 5 gRMS operating.

Highlights

  • Fast boot and load times from up to 6600 MBps sequential read
  • Quick file saves and installs with up to 5600 MBps sequential write
  • Responsive multitasking backed by up to 1,100,000 IOPS random write
  • Long service life supported by 300TB written endurance
  • Cool, low-power operation at 4 mW idle consumption

Specifications

BrandSanDisk
SeriesOptimus 5100
ModelSDSP51500GAN-000E0
Device TypeInternal Solid State Drive (SSD)
Form FactorM.2 2280
Capacity500GB
Memory ComponentsQLC 3D CBA NAND
InterfacePCI-Express 4.0 x4
ProtocolNVMe
Max Sequential ReadUp to 6600 MBps
Max Sequential WriteUp to 5600 MBps
4KB Random ReadUp to 660,000 IOPS
4KB Random WriteUp to 1,100,000 IOPS
Terabytes Written (TBW)300TB
MTBF1,750,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)4 mW
Power Consumption (Active)Average Active Power Read: 3.8W
Average Active Power Write: 3.8W
Operating Temperature0°C ~ +85°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1,500G @ 0.5 ms half-sine
Max Vibration ResistanceOperating Vibration: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating Vibration: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22mm
Depth80mm
Weight5.7g
Shipping weight0.05 kg
Package size127 × 102 × 23 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this M.2 2280 drive fit in a laptop slot that is only 22 mm wide and 80 mm long?

Yes, the drive measures 22 mm wide by 80 mm long and 2.38 mm high, matching the standard M.2 2280 slot dimensions.

Does the 500 GB capacity and 300 TBW rating suit a daily driver with heavy write workloads?

The drive offers 500 GB usable space and is rated for 300 TB of total data written, which supports several hundred gigabytes of writes per day over a typical five-year lifespan.

My motherboard has a PCIe 4.0 x4 M.2 slot — will I see the advertised 6600 MB/s read and 5600 MB/s write speeds?

When installed in a PCIe 4.0 x4 slot with NVMe support, the drive can reach up to 6600 MB/s sequential read and 5600 MB/s sequential write, provided the system cooling keeps the controller within its 0 °C to 85 °C operating range.
