Silver rackmount server chassis with twelve front drive bays

Synology Inc.

Synology DiskStation DS2422+ rackmount NAS 12-bay Ryzen 2.2GHz 32GB 24TB

SKU CH-CEW3-QTQ1G

12-bay rackmount NAS with a Ryzen 2.2GHz CPU, 32GB DDR4 ECC memory and 24TB of SATA storage for virtualisation, backup and surveillance workloads

  • Form Factor12-Bay
  • ProcessorAMD Ryzen
  • Installed Memory32GB
  • Included HDD Capacity24TB (12 x 2TB)

Included HDD Capacity 24TB (12 x 2TB)

  • Scalable 12-bay rackmount design fits intensive multi-user workloads
  • Ryzen V1500B 4-core 2.2GHz CPU powers virtualisation and container storage
  • 32GB DDR4 ECC memory ensures data integrity for critical services
  • 24TB (12 x 2TB) SATA HDDs deliver high-capacity file and backup storage
  • Four 1GbE ports with link aggregation enable fast, resilient file sharing

Server roles and capacity

The Synology DiskStation DS2422+ is a 12-bay rackmount NAS built for small and medium businesses that run iSCSI backup targets, large file shares, email servers or domain controllers. A Ryzen V1500B four-core processor at 2.2GHz and 32GB of DDR4 ECC memory drive multi-user workloads while the included 24TB of SATA storage provides high-capacity space out of the box.

Installation and common issues

The chassis arrives in a sealed box but the twelve 2TB SATA 3.5-inch drives and the memory modules are packed separately and must be installed before first use. Builders should seat each drive firmly in its bay and lock the memory into the SODIMM slots; loose connections are the most frequent cause of a drive or memory module not being recognised by DSM during initial setup.

Interface and expansion limits

Four RJ-45 1GbE ports support link aggregation and failover but remain limited to gigabit throughput, so sustained multi-gigabit transfers will saturate the network links. Two USB 3.2 ports and a single expansion port allow external storage or add-on cards, yet the single power supply and fixed 1GbE networking mean the platform cannot scale beyond its built-in connectivity without a chassis change.

Highlights

  • Scalable 12-bay rackmount design fits intensive multi-user workloads
  • Ryzen V1500B 4-core 2.2GHz CPU powers virtualisation and container storage
  • 32GB DDR4 ECC memory ensures data integrity for critical services
  • 24TB (12 x 2TB) SATA HDDs deliver high-capacity file and backup storage
  • Four 1GbE ports with link aggregation enable fast, resilient file sharing

Specifications

Form Factor12-Bay
ProcessorAMD Ryzen
Installed Memory32GB
Included HDD Capacity24TB (12 x 2TB)

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I confirm the DS2422+ is operating correctly after installation?

After powering on, connect to the DSM web interface. The dashboard will show all 12 drive bays detected, 32GB DDR4 ECC memory recognised, the Ryzen V1500B CPU at 2.2GHz, and the four 1GbE ports active with link aggregation available.

What components are included and what must I source separately?

The chassis, 12 x 2TB SATA 3.5" HDDs (24TB total) and 32GB DDR4 ECC SODIMM modules are supplied. Drives and memory are packaged separately and require installation. Rails, expansion units and additional licences are not included.

Which DS2422+ configuration suits a virtualisation host needing maximum RAM headroom?

This unit ships with 32GB DDR4 ECC SODIMM already installed. The Ryzen V1500B 4-core 2.2GHz processor and four 1GbE ports support VM and container workloads. Choose this model when you need the highest factory-fitted memory within the DS2422+ line.
