Silver 12-bay rackmount NAS chassis with front drive trays

Synology Inc.

Synology Inc. DS2422+ rackmount NAS 12-bay Ryzen 2.2GHz 32GB 96TB

SKU CH-6B02-W52VG

12-bay rackmount NAS with Ryzen 2.2GHz CPU, 32GB DDR4 ECC memory and 96TB of SATA storage

  • Form Factor12-Bay
  • ProcessorAMD Ryzen
  • Installed Memory32GB
  • Included HDD Capacity96TB (12 x 8TB)

Included HDD Capacity 96TB (12 x 8TB)

  • 12-bay rackmount chassis scales to 96TB raw capacity
  • Ryzen V1500B 4-core 2.2GHz CPU handles multi-user workloads
  • 32GB DDR4 ECC memory protects data integrity under load
  • Four 1GbE ports with link aggregation boost throughput
  • Synology DSM delivers backup, virtualization and surveillance apps

12-bay rackmount NAS for multi-user workloads

The Synology DS2422+ is a 12-bay rackmount NAS powered by a Ryzen V1500B 4-core 2.2GHz processor and 32GB DDR4 ECC SODIMM memory. It ships with 96TB of raw capacity across twelve 8TB SATA 3.5-inch drives. The unit runs Synology DSM and provides four 1GbE LAN ports with link aggregation and failover support.

Upgrade from smaller appliances

This system replaces entry-level NAS units or DAS arrays when concurrent user counts, iSCSI LUN demand, or backup retention policies exceed the limits of fewer bays and lower memory. The jump is worth it when workloads require Btrfs-based advanced LUN iSCSI service, VM and container storage, or a network video recorder for large surveillance deployments.

Limits of 1GbE and single power supply

Aggregate throughput is capped by the four 1GbE interfaces even with link aggregation, so sustained sequential transfers cannot exceed that ceiling. The single power supply creates a single point of failure for uptime-critical roles. The expansion port allows capacity growth, but the 1GbE uplink remains the bottleneck for network-intensive tasks.

Highlights

  • 12-bay rackmount chassis scales to 96TB raw capacity
  • Ryzen V1500B 4-core 2.2GHz CPU handles multi-user workloads
  • 32GB DDR4 ECC memory protects data integrity under load
  • Four 1GbE ports with link aggregation boost throughput
  • Synology DSM delivers backup, virtualization and surveillance apps

Specifications

Form Factor12-Bay
ProcessorAMD Ryzen
Installed Memory32GB
Included HDD Capacity96TB (12 x 8TB)

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What rack space and drive bay count does the DS2422+ require?

The DS2422+ is a 12-bay rackmount NAS that occupies a standard rackmount form factor; plan for a 12-drive enclosure depth.

Which components must I install myself before first boot?

The 32GB DDR4 ECC SODIMM memory and the twelve 8TB SATA 3.5" hard drives ship separately and must be installed before powering on.

What is the memory specification and maximum supported capacity for later upgrades?

It uses 32GB DDR4 ECC SODIMM; the system supports memory upgrades using compatible DDR4 ECC SODIMM modules.
