Green rectangular M.2 2280 SSD with black label and gold edge connector

Western Digital

Western Digital Blue SN570 NVMe 2TB M.2 2280 internal SSD WDS200T3B0C

SKU CH-EK10-60HDZ MPN WDS200T3B0C

A 2TB M.2 2280 NVMe drive with PCIe 3.0 x4 interface delivering up to 3500 MBps sequential reads and writes

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory ComponentsTLC
  • InterfacePCI-Express 3.0 x4

Options 2TB

  • Up to 3500 MB/s sequential read speed for fast data access
  • Up to 3500 MB/s sequential write speed for quick file transfers
  • Up to 600,000 IOPS random read performance for responsive multitasking
  • AES 256-bit hardware encryption helps protect stored data
  • 900 TBW endurance rating supports heavy workloads over time

Capacity and audience

The Western Digital Blue SN570 NVMe delivers 2TB of TLC storage on a single-sided M.2 2280 module. It targets consumer workloads that need fast sequential throughput and sustained random performance without a DRAM cache.

Build integration

The drive plugs into any PCI-Express 3.0 x4 M.2 slot and requires no extra cables or heatsink mounting. Its single-sided layout frees the opposite side of the board for other components or a motherboard shield.

Sustained load behaviour

Sequential reads and writes each reach up to 3500 MBps while random 4KB operations hit 600000 IOPS. The 900TB TBW rating and 1.5M hour MTTF indicate consistent endurance across heavy write cycles.

Highlights

  • Up to 3500 MB/s sequential read speed for fast data access
  • Up to 3500 MB/s sequential write speed for quick file transfers
  • Up to 600,000 IOPS random read performance for responsive multitasking
  • AES 256-bit hardware encryption helps protect stored data
  • 900 TBW endurance rating supports heavy workloads over time

Specifications

BrandWestern Digital
SeriesBlue SN570 NVMe
ModelWDS200T3B0C
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory ComponentsTLC
InterfacePCI-Express 3.0 x4
EncryptionAES 256-bit encryption
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 3500 MBps
4KB Random ReadUp to 600,000 IOPS
4KB Random WriteUp to 600,000 IOPS
Terabytes Written (TBW)900TB
MTTF1.5M Hours
Power Consumption (Idle)PS3 (Low Power): 30 mW
PS4 (Sleep): 5 mW
Power Consumption (Active)4.5W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1,500G @0.5 ms half sine
Max Vibration ResistanceOperating Vibration: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating Vibration: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22.00mm
Depth80.00mm
Weight6.50g
Shipping weight0.05 kg
Package size127 × 102 × 19 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much data can I write before the 900TB endurance rating is reached?

The drive is rated for 900TB of total bytes written, which is the endurance limit that appears first under sustained heavy write workloads.

What is the active power draw when the SSD runs continuously at 4.5W?

Active power consumption is 4.5W; idle drops to 30 mW in PS3 low-power state and 5 mW in PS4 sleep.

Does my motherboard need an M.2 slot wired for PCI-Express 3.0 x4 to use this NVMe drive?

Yes, the drive requires an M.2 2280 slot with PCI-Express 3.0 x4 electrical connection for full NVMe operation.
