Thin green circuit board with black chips, single sided M.2 2280 NVMe SSD

Western Digital

Western Digital WDS100T3B0C Blue SN570 1TB M.2 2280 NVMe internal SSD

SKU CH-ZYCB-ZVK0Y MPN WDS100T3B0C

1TB PCIe 3.0 x4 NVMe M.2 2280 SSD with up to 3500 MBps read and 3000 MBps write speeds

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory ComponentsTLC
  • InterfacePCI-Express 3.0 x4, NVMe v1.4

Options 1TB

  • Sequential reads up to 3500 MB/s for fast boot and load times
  • Sequential writes up to 3000 MB/s to move large files quickly
  • Random reads up to 460000 IOPS for snappy application response
  • 600 TBW endurance rating for long-term data integrity
  • Single-sided M.2 2280 design fits slim laptops and compact desktops

Blue SN570 1TB NVMe SSD

The Western Digital Blue SN570 WDS100T3B0C is a 1TB M.2 2280 internal solid-state drive built on a PCI-Express 3.0 x4 interface with NVMe 1.4. It uses TLC memory to deliver sequential reads up to 3500 MBps and writes up to 3000 MBps, with random performance reaching 460,000 read IOPS and 450,000 write IOPS. The single-sided 2.38 mm profile fits tight laptop and desktop slots while drawing 4.5 W active power and as little as 5 mW in sleep.

Ideal for mainstream builders and upgraders

This drive suits everyday computing, content creation and gaming loads that benefit from NVMe speed without demanding PCIe 4.0 bandwidth. The 600 TBW endurance rating and 1.5M-hour MTTF support heavy daily writes, while low idle power helps battery life in portable systems. Users needing sustained PCIe 4.0 throughput or higher endurance for write-intensive servers should consider other models.

Fits standard M.2 2280 slots

The 22 mm by 80 mm single-sided PCB slides into any M.2 2280 key-M socket wired for PCIe 3.0 x4 or x2, requiring no extra cables or brackets. Its 0 °C to 70 °C operating range and 1500 G shock tolerance make it reliable in thin ultrabooks and compact desktops alike. The Western Digital SSD Dashboard software adds health monitoring and firmware updates, freeing you from manual drive management.

Highlights

  • Sequential reads up to 3500 MB/s for fast boot and load times
  • Sequential writes up to 3000 MB/s to move large files quickly
  • Random reads up to 460000 IOPS for snappy application response
  • 600 TBW endurance rating for long-term data integrity
  • Single-sided M.2 2280 design fits slim laptops and compact desktops

Specifications

BrandWestern Digital
SeriesBlue SN570 NVMe
ModelWDS100T3B0C
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory ComponentsTLC
InterfacePCI-Express 3.0 x4, NVMe v1.4
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random ReadUp to 460,000 IOPS
4KB Random WriteUp to 450,000 IOPS
Terabytes Written (TBW)600TB
MTTF1.5M Hours
Power Consumption (Idle)Average Active Power: 90 mW
PS3 (Low Power): 30 mW
PS4 (Sleep): 5 mW
Power Consumption (Active)4.5W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1,500G @0.5 ms half sine
Max Vibration ResistanceOperating Vibration: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating Vibration: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22.00mm
Depth80.00mm
Weight6.50g
Shipping weight0.02 kg
Package size127 × 102 × 19 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this M.2 2280 SSD fit in my laptop that only has a single-sided slot?

Yes, the drive uses a single-sided M.2 2280 design measuring 2.38mm in height, so it fits laptops and desktops with space-constrained slots.

Does the 600 TBW endurance rating cover heavy daily workloads like video editing?

The 600 TBW rating combined with a 1.5M hour MTTF indicates the drive is built for sustained consumer workloads including content creation and large file transfers.

What software tools are available to monitor drive health and performance?

The downloadable Western Digital SSD Dashboard lets you check drive health, available space, temperature, and firmware status from within Windows.
