Aqua blue duplex multimode fibre patch cable with ST connectors, 25m length, 3.0mm jacket

Enfain

Enfain OM3 ST-ST Duplex Multimode Fibre Optic Cable 25m Aqua Blue

SKU CH-46DY-CHE6V

A 25 m aqua OM3 duplex patch cord with ST connectors, 3.0 mm jacket, ceramic ferrules, 850 nm wavelength, .2 dB typical insertion loss and >38 dB return loss for 10 Gbit links

Length 25m

  • Supports 10 Gb/s links with OM3 10-gigabit core
  • Low 0.2 dB typical insertion loss preserves signal strength
  • Return loss above 38 dB reduces reflected light
  • 0 mm PVC jacket rated for 1000 mating cycles
  • Operates from -20 °C to +60 °C for data-centre use

Enfain OM3 ST-ST Duplex Cable

The Enfain OM3 ST-ST duplex multimode fibre optic cable is built for 10G gigabit links in switches, servers and data centres. It uses a 3.0 mm PVC jacket with ceramic ferrules and an aqua blue colour code for quick identification. The 25 metre length suits rack-to-rack or cross-connect runs.

OM3 10G core capacity and headroom

The OM3 10-gigabit core supports 1G, 10G and 40G compatible transmission at 850 nm wavelength. Typical insertion loss is .2 dB and maximum insertion loss is .3 dB, while return loss exceeds 38 dB. Bandwidth headroom ends at the rated 40G compatibility and the 25 metre reach.

Thermals noise and power draw

Passive glass fibre generates no heat and produces no audible noise during operation. The cable draws no electrical power and operates reliably from -20°C to +60°C. A 330 mm bending radius and 1000 insertion cycles ensure durable handling in normal use.

Prednosti

  • Supports 10 Gb/s links with OM3 10-gigabit core
  • Low 0.2 dB typical insertion loss preserves signal strength
  • Return loss above 38 dB reduces reflected light
  • 0 mm PVC jacket rated for 1000 mating cycles
  • Operates from -20 °C to +60 °C for data-centre use

Špecifikácie

Pre tento produkt zatiaľ nie sú zverejnené žiadne špecifikácie.

Ďalšie verzie tohto modelu

Ďalších 5 v tomto rade

Rovnaký rad, iná pamäť, chladič alebo frekvencia — porovnajte pred rozhodnutím.

Otázky k tomuto produktu

Will the ST connectors on this OM3 cable mate with the older ST patch panels we already have in the rack?

Yes, the duplex ST connectors follow the standard interface used on legacy panels, so they will plug directly into your existing ST bulkheads without adapters.

How can I verify the link is performing to the rated 0.2 dB typical insertion loss after installation?

Use a light source and power meter at 850 nm; a measured loss at or below 0.3 dB confirms the cable meets its maximum specification.

Does the 25 m aqua-blue cable ship with dust caps or protective boots, or must I order them separately?

The cable arrives with protective caps on both ceramic ferrules; no extra accessories are required for immediate deployment.
