Tower server chassis with eight hot-plug drive bays, DVD drive and redundant power supplies

DELL

DELL PowerEdge T320 E5-2450 2.1GHz 8GB DDR3 H710 2x 495W rack server

SKU CH-CRMZ-40SPZ MPN E5-2450

Tower server with an eight-core 2.1GHz Xeon, 8GB DDR3, H710 RAID controller and dual 495W supplies supporting up to eight 3.5" hot-plug drives

  • TypeTower
  • Redundant Hot-swap PowerNo
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C600
  • Installed Memory Size8GB

Installed Memory Size 8GB

CPU Model E5-2450

  • Eight-core Xeon E5-2450 at 2.1 GHz for multi-thread workloads
  • 8 GB DDR3 installed across six DIMM slots for expandable memory
  • PERC H710 512 MB RAID controller supports RAID 0/1/5/6/10/50/60
  • Eight 3.5-inch hot-plug bays accept SATA or SAS drives
  • Dual 495 W redundant power supplies keep the server running

Dell PowerEdge T320 tower server

The Dell PowerEdge T320 is a tower server built around a single Intel Xeon E5-2450 eight-core processor running at 2.1 GHz. It ships with 8 GB of DDR3 memory across six DIMM slots and includes a PERC H710 RAID controller with 512 MB cache supporting RAID levels 0, 1, 5, 6, 10, 50 and 60. Dual 495 W redundant power supplies and eight 3.5-inch hot-plug drive bays complete the chassis.

Suits small-business workloads needing internal

This server fits organisations that want a tower form factor with hardware RAID and room for up to eight SATA or SAS drives. Buyers who require more than one physical CPU, memory beyond the 8 GB installed, or drive bays beyond the eight provided should look at larger platforms. The single-processor design and DDR3 memory limit expansion for compute-heavy or memory-intensive applications.

Eight 3.5-inch hot-plug bays with PERC H710 RAID

The key specification is the combination of eight hot-plug 3.5-inch bays and the H710 controller supporting RAID 0, 1, 5, 6, 10, 50 and 60. This determines whether the server can meet your storage capacity and redundancy requirements. Maximum supported raw capacity is 64 TB. No drives or trays are included, so you must source compatible SATA or SAS disks separately.

Highlights

  • Eight-core Xeon E5-2450 at 2.1 GHz for multi-thread workloads
  • 8 GB DDR3 installed across six DIMM slots for expandable memory
  • PERC H710 512 MB RAID controller supports RAID 0/1/5/6/10/50/60
  • Eight 3.5-inch hot-plug bays accept SATA or SAS drives
  • Dual 495 W redundant power supplies keep the server running

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge T320
TypeTower
Redundant Hot-swap PowerNo
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C600
Installed Memory Size8GB
Memory TypeDDR3
Max Memory Capacity8GB
Memory Features6 DIMM slots. (2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots6
Storage ControllerDell Perc H710 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementBasic management (default), iDRAC7 with Lifecycle Controller, iDRAC7 Express (upgrade option) or iDRAC7 Enterprise
(upgrade option), 8GB or 16GB vFlash media (upgrade options)
LAN Ports2 x Ports
Expansion Slots5 PCIe slots: 1 x16 with x16 bandwidth, 3.0, full-length, fullheight; 1 x8 with x4 bandwidth, 3.0, half-length, fullheight1 x8 with x4 bandwidth, 2.0, half-length, full-height; 1 x8 with x4 bandwidth, 3.0, full-length, full-height; 1 x8 with x1 bandwidth, 2.0, full-length, full-height
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How does the single Xeon E5-2450 at 2.1GHz with eight cores perform inside the T320?

The processor delivers eight physical cores and sixteen threads via Hyper-Threading, running at 2.1GHz on the Intel C600 chipset with DDR3 memory support up to 1600MT/s depending on CPU capability.

What does the H710 6Gbps RAID controller limit in practice?

The controller caps each drive link at 6Gbps and supports RAID 0, 1, 5, 6, 10, 50 and 60 with 512MB cache across up to eight 3.5-inch hot-plug SATA or SAS bays.

What physical space and power does the tower chassis need to fit and run?

The unit measures 23.42 by 11.99 by 18.55 inches, weighs 60 lbs, and requires two 495W redundant power supplies installed in the chassis.
