Tower server in dark grey chassis with front drive bays and DVD slot

DELL

DELL PowerEdge T320 E5-2420 1.9GHz 16GB DDR3 H710 2x 495W rack server

SKU CH-7T15-JZ73A MPN E5-2420

Tower server with a six-core Xeon at 1.9 GHz, 16 GB DDR3, H710 RAID controller and dual 495 W power supplies

  • TypeTower
  • Redundant Hot-swap PowerNo
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C600
  • Installed Memory Size16GB

Installed Memory Size 16GB

CPU Model E5-2420

  • Six-core Xeon E5-2420 at 1.9 GHz handles multi-threaded workloads
  • 16 GB DDR3 memory supports up to 192 GB total capacity
  • PERC H710 RAID controller with 512 MB cache enables RAID 0/1/5/6/10/50/60
  • Eight 3.5-inch hot-plug bays accept SATA or SAS drives up to 64 TB
  • Dual 495 W redundant power supplies keep the server running if one fails

Tower Server for Small-Scale Workloads

The Dell PowerEdge T320 is a tower server built around a single Intel Xeon E5-2420 six-core processor running at 1.9 GHz. It ships with 16 GB of DDR3 memory across six DIMM slots and a PERC H710 RAID controller with 512 MB cache. Dual 495 W redundant power supplies and eight hot-plug 3.5-inch drive bays support SATA or SAS drives in RAID 0, 1, 5, 6, 10, 50 or 60. A DVD-ROM drive and Matrox G200 graphics with 8 MB video memory complete the base configuration.

Suited for File, Print or Light Virtualisation Tasks

This system fits small offices or branch locations that need a quiet tower form factor with redundant power and hardware RAID. It is not for buyers who need a second processor, more than eight drive bays, or memory beyond the 192 GB maximum supported by the platform. The single-socket design limits compute density, and the DDR3 memory generation prevents reuse of newer modules. Teams requiring GPU acceleration or 10 GbE networking will need additional add-in cards.

Memory Ceiling Dictates Upgrade Path

The installed 16 GB of DDR3 can be expanded to 192 GB using the six available DIMM slots, but the memory type cannot be changed. Any future capacity increase must use DDR3 modules up to 32 GB each, and actual speed depends on the processor capability. This constraint makes the memory specification the deciding factor for whether the server can grow with the workload.

Highlights

  • Six-core Xeon E5-2420 at 1.9 GHz handles multi-threaded workloads
  • 16 GB DDR3 memory supports up to 192 GB total capacity
  • PERC H710 RAID controller with 512 MB cache enables RAID 0/1/5/6/10/50/60
  • Eight 3.5-inch hot-plug bays accept SATA or SAS drives up to 64 TB
  • Dual 495 W redundant power supplies keep the server running if one fails

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge T320
TypeTower
Redundant Hot-swap PowerNo
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C600
Installed Memory Size16GB
Memory TypeDDR3
Max Memory Capacity16GB
Memory Features6 DIMM slots. (2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots6
Storage ControllerDell Perc H710 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementBasic management (default), iDRAC7 with Lifecycle Controller, iDRAC7 Express (upgrade option) or iDRAC7 Enterprise
(upgrade option), 8GB or 16GB vFlash media (upgrade options)
LAN Ports2 x Ports
Expansion Slots5 PCIe slots: 1 x16 with x16 bandwidth, 3.0, full-length, fullheight; 1 x8 with x4 bandwidth, 3.0, half-length, fullheight1 x8 with x4 bandwidth, 2.0, half-length, full-height; 1 x8 with x4 bandwidth, 3.0, full-length, full-height; 1 x8 with x1 bandwidth, 2.0, full-length, full-height
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the PERC H710 RAID controller and what step is often missed?

The H710 is pre-installed in the dedicated slot; the step often missed is connecting the SAS cables from the controller to the 3.5-inch backplane before adding drives.

Which components will need replacement after extended operation?

The two 495 W redundant power supplies and the system fans are the field-replaceable units that typically wear out first.

What limit appears first when the Xeon E5-2420 runs at full load continuously?

The single-socket design caps performance at six cores and twelve threads, so CPU throughput is the first ceiling under sustained use.
