Tower server chassis with eight front 3.5-inch drive bays and dual power supplies

DELL

DELL PowerEdge T320 E5-2420 48GB DDR3 8×3.5" H710 2×495W

SKU CH-YH27-YX2SF MPN E5-2420

Tower server with a six-core 1.9 GHz Xeon, 48 GB DDR3, H710 RAID controller and eight hot-plug 3.5" bays

  • TypeTower
  • Redundant Hot-swap PowerNo
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C600
  • Installed Memory Size48GB

Installed Memory Size 48GB

CPU Model E5-2420

  • Six-core Xeon E5-2420 at 1.9 GHz for multi-threaded workloads
  • 48 GB DDR3 memory installed across six DIMM slots
  • PERC H710 512 MB controller supports RAID 0/1/5/6/10/50/60
  • Eight 3.5-inch hot-plug bays for SATA or SAS drives
  • Dual 495 W redundant power supplies keep the system running

Server overview

The Dell PowerEdge T320 is a tower server system built around a single Intel Xeon E5-2420 six-core processor running at 1.9 GHz with twelve virtual threads. It arrives with 48 GB of DDR3 memory installed across six DIMM slots and a Dell PERC H710 RAID controller with 512 MB cache supporting RAID levels 0, 1, 5, 6, 10, 50 and 60. Two 495 W redundant power supplies and a DVD-ROM drive complete the base configuration.

Ideal use cases

This server suits small-business workloads such as file and print serving, light virtualisation or a local database that fit within 48 GB of RAM and eight 3.5-inch hot-plug drive bays. The single-socket design and maximum memory ceiling of 48 GB mean it cannot support multi-processor scaling or larger memory footprints, so buyers needing more cores or more than 48 GB should look elsewhere.

Capacity and headroom

The chassis provides up to eight 3.5-inch SATA or SAS hot-plug bays with a total raw capacity limit of 64 TB, while the H710 controller handles 6 Gbps throughput for the configured RAID array. Memory is fixed at the installed 48 GB because the platform maximum matches the current population, leaving no headroom for RAM expansion. Five PCIe slots — one full-length x16 Gen 3.0, three x8 slots (two Gen 3.0, one Gen 2.0) and one x8 slot wired x1 Gen 2.0 — offer room for additional NICs, HBAs or other add-in cards.

Highlights

  • Six-core Xeon E5-2420 at 1.9 GHz for multi-threaded workloads
  • 48 GB DDR3 memory installed across six DIMM slots
  • PERC H710 512 MB controller supports RAID 0/1/5/6/10/50/60
  • Eight 3.5-inch hot-plug bays for SATA or SAS drives
  • Dual 495 W redundant power supplies keep the system running

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge T320
TypeTower
Redundant Hot-swap PowerNo
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C600
Installed Memory Size48GB
Memory TypeDDR3
Max Memory Capacity48GB
Memory Features6 DIMM slots. (2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots6
Storage ControllerDell Perc H710 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementBasic management (default), iDRAC7 with Lifecycle Controller, iDRAC7 Express (upgrade option) or iDRAC7 Enterprise
(upgrade option), 8GB or 16GB vFlash media (upgrade options)
LAN Ports2 x Ports
Expansion Slots5 PCIe slots: 1 x16 with x16 bandwidth, 3.0, full-length, fullheight; 1 x8 with x4 bandwidth, 3.0, half-length, fullheight1 x8 with x4 bandwidth, 2.0, half-length, full-height; 1 x8 with x4 bandwidth, 3.0, full-length, full-height; 1 x8 with x1 bandwidth, 2.0, full-length, full-height
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What drives do I need to populate the 8×3.5" hot-plug bays?

The bays accept 3.5" SATA or SAS hard drives or SSDs; drives and trays are not included.

Can I keep using the PERC H710 controller with older 3Gbps SAS drives?

Yes, the H710 6Gbps controller is backward compatible with 3Gbps SAS and SATA drives.

How do I verify the H710 RAID controller is healthy after installation?

During POST press Ctrl+R to enter the H710 BIOS utility and confirm the controller firmware version, battery status and virtual-disk state show optimal.
