Tower server in black metal chassis with front drive bays and DVD slot

DELL

DELL E5-2420 PowerEdge T320 Tower Server 32GB DDR3 2x 495W

SKU CH-2V2D-FNB7F MPN E5-2420

Tower server with a six-core 1.9 GHz Xeon, 32 GB DDR3, eight 3.5″ hot-plug bays and dual 495 W supplies

  • TypeTower
  • Redundant Hot-swap PowerNo
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C600
  • Installed Memory Size32GB

Installed Memory Size 32GB

CPU Model E5-2420

  • Six-core Xeon E5-2420 at 1.9 GHz handles multi-threaded workloads
  • 32 GB DDR3 memory installed across six DIMM slots
  • H710 RAID controller with 512 MB cache supports RAID 0, 1, 5, 6, 10, 50, 60
  • Eight 3.5-inch hot-plug bays accept SATA or SAS drives
  • Dual 495 W redundant power supplies keep the system running if one fails

Dell PowerEdge T320 Tower Server

The Dell PowerEdge T320 is a tower server built around a single Intel Xeon E5-2420 six-core processor running at 1.9GHz with twelve virtual threads. It ships with 32GB of DDR3 memory installed across six DIMM slots and includes a Dell PERC H710 RAID controller with 512MB cache. Dual 495W redundant power supplies and eight hot-plug 3.5-inch drive bays complete the base configuration.

Memory capacity fixed at 32GB DDR3

The system arrives with 32GB of DDR3 already populated and the specifications list the maximum supported capacity as 32GB, so no further memory upgrades are possible. Buyers who need more than 32GB of RAM should consider a different platform because the installed modules fill every slot and the chipset ceiling prevents expansion.

Tool-less drive bays and standard PCIe slots

Eight front-access hot-plug bays accept 3.5-inch SATA or SAS drives without tools, and the PERC H710 supports RAID 0, 1, 5, 6, 10, 50 and 60. Five PCIe slots (one x16 at 3.0, three x8 at x4 bandwidth and one x8 at x1) use standard full-height brackets, so common add-in cards fit without adapters. No drives or trays are included, so budget for those separately.

Highlights

  • Six-core Xeon E5-2420 at 1.9 GHz handles multi-threaded workloads
  • 32 GB DDR3 memory installed across six DIMM slots
  • H710 RAID controller with 512 MB cache supports RAID 0, 1, 5, 6, 10, 50, 60
  • Eight 3.5-inch hot-plug bays accept SATA or SAS drives
  • Dual 495 W redundant power supplies keep the system running if one fails

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge T320
TypeTower
Redundant Hot-swap PowerNo
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C600
Installed Memory Size32GB
Memory TypeDDR3
Max Memory Capacity32GB
Memory Features6 DIMM slots. (2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots6
Storage ControllerDell Perc H710 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementBasic management (default), iDRAC7 with Lifecycle Controller, iDRAC7 Express (upgrade option) or iDRAC7 Enterprise
(upgrade option), 8GB or 16GB vFlash media (upgrade options)
LAN Ports2 x Ports
Expansion Slots5 PCIe slots: 1 x16 with x16 bandwidth, 3.0, full-length, fullheight; 1 x8 with x4 bandwidth, 3.0, half-length, fullheight1 x8 with x4 bandwidth, 2.0, half-length, full-height; 1 x8 with x4 bandwidth, 3.0, full-length, full-height; 1 x8 with x1 bandwidth, 2.0, full-length, full-height
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the 1.9 GHz Xeon E5-2420 actually deliver in this server?

The six-core processor runs at 1.9 GHz with Hyper-Threading giving 12 logical threads, suited for multi-threaded workloads such as virtualisation or database tasks within the T320 platform.

How does the H710 controller's 6 Gbps limit affect drive choices?

The Perc H710 tops out at 6 Gbps per port, so SAS or SATA SSDs and HDDs will be capped at that throughput; faster drives will not exceed the controller's link speed.

What clearance and power do the five PCIe slots need for add-in cards?

The tower chassis provides one full-length x16 Gen 3 slot, three full-length x8 slots (two Gen 3, one Gen 2) and one half-length x8 Gen 3 slot, all full-height, powered by dual 495 W supplies.
