Black ATX motherboard with silver heatsinks, AM5 socket, four DDR5 slots, multiple M.2 shields, 5G LAN and Wi-Fi 7 antennas

MSI

MSI MPG X870E EDGE TI WIFI + Ryzen 7 9800X3D AMD motherboard & CPU combo

SKU CH-YNM5-PP93F

AM5 motherboard with Ryzen 7 9800X3D, four DDR5 slots up to 256GB, four M.2 sockets, PCIe 5.0 graphics slot, 5G LAN and Wi-Fi 7

  • CPU Socket TypeAM5
  • CPU TypeSupports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processo
  • ChipsetAMD X870E
  • Number of Memory Slots4x288pin (DDR5)
  • Memory Standard4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support
  • Maximum Memory Supported256GB

CPU +Ryzen 7 9800X3D

  • AM5 socket supports Ryzen 9000, 8000 and 7000 series CPUs
  • Four DDR5 slots reach 8400 MT/s overclocked for 256 GB capacity
  • PCIe 5.0 x16 slot and four M.2 sockets deliver 128 GB/s bandwidth
  • 5G LAN plus Wi-Fi 7 with 320 MHz channel for fast networking
  • Premium thermal design with heat-pipe MOSFET heatsink and M.2 Shield Frozr

Socket AM5 combo for high-end gaming builds

This bundle pairs the MSI MPG X870E EDGE TI WIFI motherboard with the AMD Ryzen 7 9800X3D processor. The board supports Ryzen 9000, 8000 and 7000 series CPUs on the AM5 platform. Four DDR5 slots accept up to 256 GB of memory in dual-channel mode. It is aimed at enthusiasts who want a ready-to-run foundation for a powerful gaming system.

Premium thermal design

A heavy plated MOSFET heatsink linked by a heat-pipe works with 7.1 W/mK thermal pads and extra choke pads to move heat away from the power delivery. Onboard M.2 Shield Frozr coolers keep the four M.2 slots at lower temperatures during sustained loads. The 5G LAN and Wi-Fi 7 controllers add minimal extra heat. Fan headers let you tune airflow for quiet operation under typical gaming workloads.

2nd-gen AMD 3D V-Cache technology on the Ryzen 7

The included CPU uses second-generation 3D V-Cache to deliver a large L3 cache block directly on the compute die. This architecture reduces latency for gaming workloads and pushes frame rates higher in cache-sensitive titles. The processor drops into the same AM5 socket as other Ryzen 7000, 8000 and 9000 series chips, so the platform remains upgradeable for future releases.

Highlights

  • AM5 socket supports Ryzen 9000, 8000 and 7000 series CPUs
  • Four DDR5 slots reach 8400 MT/s overclocked for 256 GB capacity
  • PCIe 5.0 x16 slot and four M.2 sockets deliver 128 GB/s bandwidth
  • 5G LAN plus Wi-Fi 7 with 320 MHz channel for fast networking
  • Premium thermal design with heat-pipe MOSFET heatsink and M.2 Shield Frozr

Specifications

BrandMSI
SeriesMPG X870E EDGE TI WIFI+R7 9800X3D
ModelMPG X870E EDGE TI WIFI+R7 9800X3D
Part NumberMPG X870E EDGE TI WIFI
CPU Socket TypeAM5
CPU TypeSupports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
ChipsetAMD X870E
Number of Memory Slots4x288pin (DDR5)
Memory Standard4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory Support DDR5 8400 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s
Ryzen™ 9000 Series Processors max. overclocking frequency:
• 1DPC 1R Max speed up to 8400+ MT/s
• 1DPC 2R Max speed up to 6400+ MT/s
• 2DPC 1R Max speed up to 6400+ MT/s
• 2DPC 2R Max speed up to 4800+ MT/s
Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPOTM
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only*
* CUDIMM support and POR boot frequency may vary by CPU series, with manua
Maximum Memory Supported256GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
PCI Express 5.0 x161 x PCI Express 5.0 x16
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI SlotsPCI_E1 slot
• Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors)
• Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
• Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor)
Serial ATA (SATA)4 x SATA 6Gb/s
M.24x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280 devices
M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
4x SATA 6G
M.2_1 slot
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors)
M.2_2 slot
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• The M2_2 slo
Audio ChannelsRealtek® ALC4080 Codec
7.1-Channel USB High-Performance Audio
Supports up to 32-Bit/384 kHz playback on front panel
Supports S/PDIF output
Max LAN Speed1x Realtek® 8126 5G LAN
Wireless LANWi-Fi 7
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
Supports Bluetooth® 5.4**, MLO, 4KQAM
* 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
BluetoothYes
Back I/O PortsClear CMOS Button
USB 10Gbps Type-A
USB 2.0
5G LAN
Wi-Fi / Bluetooth
Audio Connectors
Flash BIOS Button
HDMI™
USB 40Gbps Type-C
USB 10Gbps Type-A
USB 10Gbps Type-C
Optical S/PDIF Out
Other Connectors1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x Front Type-C Quick Charge Connector(PD_PWR1)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
6x System Fan
1x EZ Conn-header (JAF_2)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports
1x USB 20Gbps Type C ports
Form FactorATX
Dimensions (W x L)243.84mmx304.8mm
Windows 11Support for Windows® 11 64-bit
FeaturesSupports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Supports DDR5 Memory, Dual Channel DDR5 8400+ MT/s (OC)
Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 8-layer PCB made by 2oz thickened copper and server-grade level material
Frozr Guard: Enlarged heatsink with heat-pipe, MOSFET thermal pads rated for 7W/mk, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
EZ DIY: EZ PCIe Release, EZ M.2 Shield Frozr II, EZ M.2 Clip II and EZ Antenna
Ligh

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the Ryzen 7 9800X3D into the AM5 socket on this board, and which step catches people out?

Lift the retention arm, align the gold triangle on the CPU with the socket marker, lower the chip straight down without pressure, then close and latch the arm; the common mistake is applying force before the processor seats fully.

What maintenance will the MPG X870E EDGE TI WIFI need over time?

Dust the heavy plated MOSFET heatsink, heat-pipe and M.2 Shield Frozr fins periodically; the 7 W/mK MOSFET thermal pads and choke pads are rated for the board's service life and do not require scheduled replacement.

What limit appears first when the X870E chipset and 5G LAN run sustained heavy loads?

The Realtek 8126 5G LAN controller caps wired throughput at 5 Gb/s, so extended large transfers will hit that ceiling before the PCIe 5.0 or 4.0 lanes saturate.
