ATX motherboard in dark grey with silver heatsinks and a boxed Ryzen 5 9600X CPU

MSI

MSI PRO X870E-P WIFI + Ryzen 5 9600X AMD motherboard CPU combo

SKU CH-Q7TZ-MGVEP

A motherboard and CPU bundle with AM5 socket, X870E chipset, DDR5 memory up to 8200 MT/s, Wi-Fi 7, 5G LAN and PCIe 5.0 graphics support

  • CPU Socket TypeAM5
  • ChipsetAMD X870E
  • Number of Memory Slots4x288pin (DDR5)
  • Memory StandardMemory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JED
  • Maximum Memory Supported256GB
  • Channel SupportedDual Channel

CPU +Ryzen 5 9600X

  • Ready-to-build combo with Ryzen 5 9600X CPU installed
  • DDR5 memory overclocks to 8200 MT/s for fast throughput
  • PCIe 5.0 x16 slot delivers 128 Gbps bandwidth to graphics card
  • Wi-Fi 7 with 320 MHz channel reaches 5.8 Gbps wireless speed
  • 5G LAN plus Bluetooth 5.4 give flexible high-speed connectivity

Combo for AM5 builds

This bundle pairs an AMD X870E motherboard with a Ryzen 5 9600X processor. It targets builders who want a ready-to-run platform for current and future AM5 CPUs. The board supplies four DDR5 slots, a PCIe 5.0 x16 slot and three M.2 connectors. Wireless and wired networking are built in.

Check BIOS, memory and cooler clearance

Verify that the board ships with a BIOS supporting the 9600X or be prepared to update using an older AM5 CPU. Install DDR5 modules rated for 4800 to 8200 MT/s in dual-channel pairs up to 256 GB. Confirm your CPU cooler fits the AM5 mounting pattern and does not block the first PCIe slot or M.2 heatsinks. Ensure the power supply provides an 8-pin EPS connector for the 60A SPS VRM.

Thermals noise and power

The 60A SPS VRM handles the 9600X at stock settings without active VRM fans. Frozr AI Cooling monitors CPU and GPU temperatures and adjusts system fan curves automatically. The M.2 Shield Frozr covers each drive slot to limit throttle under sustained transfers. Typical system noise stays low during desktop work and moderate under heavy compile or render loads.

Highlights

  • Ready-to-build combo with Ryzen 5 9600X CPU installed
  • DDR5 memory overclocks to 8200 MT/s for fast throughput
  • PCIe 5.0 x16 slot delivers 128 Gbps bandwidth to graphics card
  • Wi-Fi 7 with 320 MHz channel reaches 5.8 Gbps wireless speed
  • 5G LAN plus Bluetooth 5.4 give flexible high-speed connectivity

Specifications

BrandMSI
ModelPRO X870E-P WIFI+R5 9600X
Part NumberPRO X870E-P WIFI+R5 9600X
CPU Socket TypeAM5
ChipsetAMD X870E
Number of Memory Slots4x288pin (DDR5)
Memory StandardMemory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s
Ryzen™ 9000 Series Processors max. overclocking frequency:
• 1DPC 1R Max speed up to 8200+ MT/s
• 1DPC 2R Max speed up to 6400+ MT/s
• 2DPC 1R Max speed up to 6400+ MT/s
• 2DPC 2R Max speed up to 6000+ MT/s
Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPOTM
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only*
* CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain
Maximum Memory Supported256GB
Channel SupportedDual Channel
PCI Express 5.0 x16PCI_E1 slot
- Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors)
- Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors)
- Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processors)
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express x4PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
PCI Express x1PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2 Gen5 x4 128Gbps slots,
2 x M.2 Gen4 x 4 64 Gbps slots,
LAN ChipsetRealtek@ 8126 5G LAN
Wireless LANWi-Fi 7 Solution,
BluetoothBluetooth 5.4
HDMISupport 4K@60Hz as specified in HDMITM 2.1
RJ451 x RJ45
USB 3.12x USB 10Gbps Type-A
1 x USB 5Gbps Type- A
USB 1.1/2.04 x USB 2.0
USB Type-C1 x USB4 port supports USB Type-C display output,
- Requires Processor Graphics
1 x USB 20Gbps Type-C
Audio Ports8-Channel(7.1) HD Audio with Audio Boost.
Form FactorATX

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this combo fit in a standard ATX case and work with my existing DDR5 memory?

The board uses the AM5 socket and four 288-pin DDR5 slots supporting up to 256 GB in dual-channel mode. JEDEC speeds run at 4800 and 5600 MT/s; overclocked speeds reach 8200+ MT/s with one single-rank DIMM per channel or 6400+ MT/s with two ranks per channel.

What high-speed storage can I install without adding extra cards?

Three onboard M.2 slots are provided: one Gen5 x4 at 128 Gbps and two Gen4 x4 at 64 Gbps each, plus four SATA 6 Gb/s ports for additional drives.

Which network and USB connections are built in for fast wired and wireless links?

A Realtek 8126 5G LAN port and Wi-Fi 7 with a 320 MHz channel (up to 5.8 Gbps) handle networking, while Bluetooth 5.4 and a USB4 40 Gbps port provide high-speed peripheral connectivity.
