Solidigm D5-P5430 15.36TB E3.S 7.5mm enterprise SSD, rectangular bare board with edge connector and label

Solidigm

Solidigm D5-P5430 15.36TB E3.S 7.5mm enterprise SSD SBFPFABU153T001

SKU CH-MWKQ-KXAWS MPN SBFPFABU153T001

15.36 TB E3.S 7.5 mm enterprise SSD with 192-layer QLC 3D NAND and PCIe 4.0 x4 interface, rated for 2,000,000 hours MTBF

  • Form FactorE3.S 7.5mm
  • Capacity15.36TB
  • Memory Components192L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • MTBF2,000,000 hours
  • Operating Temperature0°C ~ +70°C

Option 15.36TB E3.S

Show 14 more configurations
  • 36 TB capacity handles massive read-intensive workloads
  • E3.S 7.5 mm form factor fits dense server chassis
  • PCIe 4.0 x4 interface delivers high throughput
  • 192-layer QLC 3D NAND enables cost-efficient density
  • 2,000,000-hour MTBF indicates enterprise-grade endurance

High-capacity E3.S drive for read-intensive servers

The Solidigm D5-P5430 delivers 15.36TB in a 7.5mm E3.S module built for dense server chassis. It uses 192L QLC 3D NAND and a PCI-Express 4.0 x4 interface to serve capacity-first workloads such as content repositories, warm data tiers and logging archives. The single-pack drive is designed for internal data-centre deployment where space and power budgets are tight.

Sustained behaviour under continuous read load

A 2,000,000-hour MTBF rating reflects the firmware and NAND tuning chosen for steady-state endurance rather than burst speed. The controller maintains consistent throughput during long sequential scans while operating between 0°C and 70°C. Vibration tolerance is rated at 2.17 GRMS across 5 to 700 Hz during operation and 3.13 GRMS across 5 to 800 Hz when powered off, and the drive withstands 1,000 G shock at 0.5 msec.

QLC endurance profile decides fit

The 192-layer QLC architecture prioritises capacity per die over write cycles, so the drive suits workloads that write infrequently and read heavily. Buyers who need higher write endurance or mixed-use durability should evaluate alternative media. The PCIe 4.0 x4 link and E3.S 7.5mm form factor are fixed; systems requiring a different connector or height cannot use this module.

Highlights

  • 36 TB capacity handles massive read-intensive workloads
  • E3.S 7.5 mm form factor fits dense server chassis
  • PCIe 4.0 x4 interface delivers high throughput
  • 192-layer QLC 3D NAND enables cost-efficient density
  • 2,000,000-hour MTBF indicates enterprise-grade endurance

Specifications

BrandSolidigm
SeriesD5-P5430
ModelD5-P5430
Form FactorE3.S 7.5mm
Capacity15.36TB
Memory Components192L QLC 3D NAND
InterfacePCI-Express 4.0
MTBF2,000,000 hours
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Shipping weight2.80 kg
Package size339 × 201 × 134 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much heat does the 15.36TB E3.S 7.5mm drive generate during all-day operation?

The drive is rated for an operating temperature range of 0°C to +70°C, so it is built to handle continuous workloads within standard server airflow limits.

What server slot is required to install this E3.S 7.5mm PCIe 4.0 x4 SSD?

You need an open E3.S 7.5mm drive bay with a PCIe 4.0 x4 electrical connection and compatible backplane power delivery.

Will this PCIe 4.0 drive work in a PCIe 3.0 backplane I already use?

Yes, the PCIe 4.0 interface is backward compatible and will operate at PCIe 3.0 speeds in an older backplane.
