Rectangular E3.S 7.5mm SSD with green circuit board and gold edge connector

Solidigm

Solidigm D5-P5430 3.84TB E3.S 7.5mm enterprise SSD SBFPFABU038T001

SKU CH-MJX2-V64F2 MPN SBFPFABU038T001

Enterprise SSD with 3.84 TB of 192-layer QLC NAND in an E3.S 7.5 mm form factor using PCIe 4.0 x4

  • Form FactorE3.S 7.5mm
  • Capacity3.84TB
  • Memory Components192L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • MTBF2,000,000 hours
  • Operating Temperature0°C ~ +70°C

Option 3.84TB E3.S

Show 14 more configurations
  • High-density 3.84 TB capacity fits read-intensive workloads
  • E3.S 7.5 mm form factor enables dense server chassis designs
  • PCI-Express 4.0 x4 interface delivers high-throughput data transfer
  • 192-layer QLC 3D NAND provides cost-efficient flash storage
  • 2 000 000 hours MTBF supports continuous data-centre operation

E3.S 7.5mm form factor

The Solidigm D5-P5430 is a 3.84TB enterprise SSD built for dense server deployments. Its E3.S 7.5mm form factor fits hot-plug bays designed for high-capacity flash storage. The drive targets data-centre operators who need read-intensive endurance in a compact package.

3.84TB QLC capacity and endurance

192L QLC 3D NAND provides 3.84TB of storage for read-heavy workloads such as content delivery and analytics. Sequential throughput scales with PCIe 4.0 x4, while sustained random writes will saturate sooner than TLC alternatives. The 2,000,000-hour MTBF rating reflects confidence in typical read-dominant duty cycles.

PCIe 4.0 x4 interface requirement

This drive requires a PCIe 4.0 x4 electrical connection in an E3.S backplane to deliver rated performance. Systems limited to PCIe 3.0 or x2 lane widths will constrain bandwidth and may not support hot-plug management features. Verify backplane and controller compatibility before deployment.

Highlights

  • High-density 3.84 TB capacity fits read-intensive workloads
  • E3.S 7.5 mm form factor enables dense server chassis designs
  • PCI-Express 4.0 x4 interface delivers high-throughput data transfer
  • 192-layer QLC 3D NAND provides cost-efficient flash storage
  • 2 000 000 hours MTBF supports continuous data-centre operation

Specifications

BrandSolidigm
SeriesD5-P5430
ModelD5-P5430
Form FactorE3.S 7.5mm
Capacity3.84TB
Memory Components192L QLC 3D NAND
InterfacePCI-Express 4.0
MTBF2,000,000 hours
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Shipping weight2.80 kg
Package size339 × 201 × 134 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the PCIe 4.0 x4 E3.S 7.5mm drive work in a server backplane that only has PCIe 3.0 slots?

The drive uses PCI-Express 4.0 x4; it will operate in a PCIe 3.0 slot at PCIe 3.0 speeds because the interface is backward compatible.

How can I verify the 192L QLC 3D NAND SSD is healthy after installation?

Check the drive SMART data for media wear indicator, temperature within 0°C to +70°C, and confirm the firmware reports 3.84TB capacity.

Does the single-pack E3.S 7.5mm unit include a heatsink or mounting screws, or must I buy them separately?

The single pack contains only the SSD; E3.S heatsinks and retention screws are supplied by the server chassis vendor and must be sourced separately.
