Aqua blue duplex fibre cable with SC and ST connectors, 25m length

Enfain

Enfain OM3 SC-ST Duplex Multimode Fibre Optic Cable 25m

SKU CH-XQC9-YV81F

OM3 duplex multimode patch cable with SC and ST connectors, 25 m length, 3.0 mm jacket, 850 nm wavelength, 0.2 dB typical insertion loss and >38 dB return loss for 10 Gbit links

Length 25m

  • Low insertion loss with .2 dB typical and .3 dB maximum
  • High return loss exceeding 38 dB for signal integrity
  • Supports 10 Gb/s over 850 nm wavelength
  • Durable ceramic ferrules rated for 1000 mating cycles
  • Flexible 3.0 mm PVC jacket with 330 mm bend radius

25 m OM3 duplex patch cable

This 25 metre OM3 multimode patch cable uses SC and ST connectors for 10 gigabit links at 850 nm. It suits data centres, servers and switches that need duplex fibre runs over moderate distances. The aqua jacket identifies the OM3 grade at a glance.

Before ordering check connector types

Verify that both ends of your link accept SC and ST interfaces respectively. Confirm the equipment operates at 850 nm and supports OM3 multimode bandwidth for the required reach. Ensure the 3.0 mm jacket fits your cable management and panel density.

Low loss and wide temperature range

Typical insertion loss is .2 dB with a maximum of .3 dB, while return loss exceeds 38 dB. The cable is rated for 1000 mating cycles and operates from -20 °C to +60 °C. A minimum bend radius of 330 mm protects performance during routing.

商品特色

  • Low insertion loss with .2 dB typical and .3 dB maximum
  • High return loss exceeding 38 dB for signal integrity
  • Supports 10 Gb/s over 850 nm wavelength
  • Durable ceramic ferrules rated for 1000 mating cycles
  • Flexible 3.0 mm PVC jacket with 330 mm bend radius

商品規格

本商品目前尚未公佈規格。

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

What connectors come on the 25m OM3 cable and is any extra hardware needed?

The cable has SC and ST duplex connectors pre-terminated; no additional hardware is required for a standard patch connection.

Should I choose this OM3 10G version or a different fibre grade for 10G links?

OM3 with an 850nm core supports 10G over the full 25m length, matching the stated 10G compatibility.

What does the 0.2dB typical insertion loss mean for a live 10G link?

Typical loss of 0.2dB leaves ample margin for 10G transmission across the 25m run.
