Green rectangular circuit board with gold edge connector and black controller chip, M.2 2280 form factor

Intel

Intel 760p Series 2TB M.2 2280 PCIe 3.0 x4 internal SSD SSDPEKKW020T8X1

SKU CH-Q877-AT0BQ MPN SSDPEKKW020T8X1

A 2TB M.2 2280 PCIe 3.0 x4 internal SSD delivering up to 3230 MBps sequential read and 1625 MBps sequential write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D2 TLC
  • InterfacePCI-Express 3.0 x4

Options 2TB

  • 2TB capacity stores large game libraries and media projects
  • PCIe 3.0 x4 interface delivers up to 3230 MBps sequential read speed
  • 340,000 IOPS random read accelerates application launch and file access
  • 576 TBW endurance rating supports heavy daily workloads
  • 25 mW idle power consumption extends laptop battery life

Intel 760p 2TB M.2 2280 PCIe 3.0 x4

The Intel 760p Series SSDPEKKW020T8X1 is an internal solid-state drive built in the M.2 2280 form factor with a 2TB capacity. It connects through a PCI-Express 3.0 x4 interface and uses 3D2 TLC memory components for consumer workloads.

Suits builds needing 2TB on an M.2 slot

This drive fits systems that provide an M.2 2280 slot wired for PCI-Express 3.0 x4 and need 2TB of storage. Builds limited to PCIe 2.0 or x2 lane configurations will not reach the stated sequential and random performance figures.

PCIe 3.0 x4 interface decides compatibility

The drive requires an M.2 2280 slot operating at PCI-Express 3.0 x4 to deliver up to 3230 MBps sequential read and 1625 MBps sequential write. Without that link width and generation the rated 340,000 IOPS random read and 275,000 IOPS random write cannot be achieved.

Highlights

  • 2TB capacity stores large game libraries and media projects
  • PCIe 3.0 x4 interface delivers up to 3230 MBps sequential read speed
  • 340,000 IOPS random read accelerates application launch and file access
  • 576 TBW endurance rating supports heavy daily workloads
  • 25 mW idle power consumption extends laptop battery life

Specifications

BrandIntel
Series760p Series
ModelSSDPEKKW020T8X1
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D2 TLC
InterfacePCI-Express 3.0 x4
Max Sequential ReadUp to 3230 MBps
Max Sequential WriteUp to 1625 MBps
4KB Random ReadUp to 340,000 IOPS
4KB Random WriteUp to 275,000 IOPS
MTBF1,600,000 hours
FeaturesEndurance Rating (Lifetime Writes): 576 TBW
Power Consumption (Idle)25 mW
Power Consumption (Active)50 mW
Operating Temperature0°C ~ +70°C
Max Shock Resistance1000G
Max Vibration ResistanceOperating: 2.17 GRMS (5-700 Hz)
Non-operating: 3.13 GRMS (5-800 Hz)
Height2.38mm
Width22.00mm
Depth80.00mm
Weight< 10.00g
Shipping weight0.08 kg
Package size130 × 94 × 20 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this 2 TB M.2 2280 drive fit in a laptop slot that only accepts 80 mm modules?

Yes, the 2280 form factor is exactly 80 mm long, so it fits any standard M.2 2280 slot.

Does the PCIe 3.0 x4 interface require a specific motherboard key or chipset?

It works in any M.2 slot wired for PCIe 3.0 x4 (M-key), which is standard on most boards from the last several years.

What does the 576 TBW endurance rating mean for daily use?

It guarantees the drive can accept 576 terabytes of total writes, enough for hundreds of gigabytes per day over the rated lifespan.
