Green circuit board M.2 2280 SSD with black controller and NAND chips, no heatsink, thin 2.1mm profile

KingSpec

KingSpec XG 7000 8TB M.2 2280 PCIe 4.0 NVMe 1.4 internal SSD

SKU CH-FTS8-P311C

8 TB M.2 2280 PCIe 4.0 NVMe 1.4 SSD with up to 7400 MB/s read, 6600 MB/s write, 720,000 read IOPS, 800,000 write IOPS, 4000 TBW, 1,000,000-hour MTBF and 2.1 mm height

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity8TB
  • Memory Components3D NAND
  • InterfacePCI-Express 4.0 x4

Options XG 7000-8TB

Struck-through versions exist but are not stocked here.

  • Up to 7400 MB/s sequential read for rapid data access
  • Up to 6600 MB/s sequential write for fast file transfers
  • 8 TB capacity stores large game libraries and media
  • 4000 TBW endurance rating supports heavy workloads
  • PCIe 4.0 x4 NVMe 1.4 interface enables high bandwidth

KingSpec XG 7000 8TB PCIe 4.0 NVMe SSD

This internal solid-state drive delivers up to 7400MBps sequential read and 6600MBps sequential write speeds over a PCI-Express 4.0 x4 interface with NVMe 1.4 protocol. It uses 3D NAND flash to provide an 8TB capacity suitable for desktops, laptops and PS5 consoles. The M.2 2280 form factor measures 80.0mm by 22.0mm by 2.1mm and is rated for 4000TB written and 1,000,000 hours MTBF.

Check motherboard M.2 slot key and PCIe generation

Verify that your system has an M-keyed M.2 2280 slot wired for PCIe 4.0 x4 to reach the advertised 7400MBps read and 6600MBps write performance. The drive is backward compatible with PCIe 3.0 slots, though speeds will be limited to the older generation. Ensure the operating system supports NVMe 1.4 and that the BIOS is updated for full device recognition. Physical clearance of 2.1mm height must be available in the target chassis or PS5 expansion bay.

Thermals noise and power draw in normal use

Idle power consumption is 0.66W while active use draws up to 8.18W under sustained workloads. The graphene-based thermal spreader dissipates heat without a moving fan, so the drive produces no audible noise during operation. Intelligent thermal control algorithms dynamically adjust workload to maintain stable temperatures during extended gaming, editing or large file transfers.

Highlights

  • Up to 7400 MB/s sequential read for rapid data access
  • Up to 6600 MB/s sequential write for fast file transfers
  • 8 TB capacity stores large game libraries and media
  • 4000 TBW endurance rating supports heavy workloads
  • PCIe 4.0 x4 NVMe 1.4 interface enables high bandwidth

Specifications

BrandKingSpec
SeriesXG70000
ModelXG7000-8TB 2280
Part NumberXG7000-8TB 2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity8TB
Memory Components3D NAND
InterfacePCI-Express 4.0 x4
ProtocolNVMe 1.4
Max Sequential ReadUp to 7400 MBps
Max Sequential WriteUp to 6600 MBps
4KB Random ReadUp to 720,000 IOPS
4KB Random WriteUp to 800,000 IOPS
Terabytes Written (TBW)4000TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)0.66W
Power Consumption (Active)8.18W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5-95%
Height80mm
Width22mm
Depth2.1mm
Weight30g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the XG 7000 8TB come with a heatsink or do I need to buy one separately?

The drive has an integrated graphene-based heat spreader built in, so no separate heatsink purchase is required for installation.

Should I pick the 8TB model or a smaller capacity for my PS5?

The 8TB version provides the maximum 4000TBW endurance and 7400MB/s read speed, making it the best choice for large game libraries.

Will I actually see 7400MB/s speeds in my desktop?

Real-world throughput reaches the rated 7400MB/s read and 6600MB/s write on a PCIe 4.0 x4 slot; on a 3.0 slot speeds are limited by the bus.
