Green circuit board with gold edge connector and silver label, small rectangular shape with attached heatsink

KingSpec

KingSpec XG7000-512 2242 internal SSD

SKU CH-TM36-BD0XS

Compact M.2 2242 PCIe 4.0 x4 SSD delivers 512 GB capacity with sequential reads up to 7000 MB/s and writes up to 4200 MB/s, plus an integrated heatsink for sustained performance in thin laptops

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity512GB
  • Memory Components3D NAND
  • InterfacePCI-Express 4.0 x4

Options XG 7000-512 2242

Struck-through versions exist but are not stocked here.

  • Sequential reads reach 7000 MBps for fast boot and load times
  • Sequential writes hit 4200 MBps to move large files quickly
  • Random 4K reads up to 630000 IOPS keep multitasking responsive
  • PCIe 4.0 x4 with NVMe 1.4 enables the high throughput
  • 3D NAND and 1000000 hour MTBF support long-term reliability

Capacity and interface

The KingSpec XG7000-512 2242 is a 512GB internal SSD built on the PCIe 4.0 x4 interface with NVMe 1.4 support. It uses 3D NAND flash and includes a heatsink for thermal management. Sequential speeds reach up to 7000 MB/s read and 4200 MB/s write. Random performance hits 630,000 IOPS read and 570,000 IOPS write.

Installation notes

The drive fits an M.2 2242 slot with M-key and measures 42.0mm by 22.0mm by 3.5mm. It runs on DC 3.3V ±5% and draws 0.63W idle or 3.50W active. The 2242 length is shorter than the common 2280 form factor, so verify your motherboard or laptop has a dedicated 2242 standoff or a combo slot. Without the correct standoff the screw will not reach.

Compatibility checks

Confirm your system provides an M.2 slot wired for PCIe 4.0 x4 and accepts 2242-length modules. Supported operating systems include Windows 10, Windows 11, Windows Server 2012 R2, RHEL, CentOS, Ubuntu and Linux. The drive operates from 0°C to 70°C and stores from -20°C to 75°C. Certifications cover CE, RoHS, FCC and REACH.

Highlights

  • Sequential reads reach 7000 MBps for fast boot and load times
  • Sequential writes hit 4200 MBps to move large files quickly
  • Random 4K reads up to 630000 IOPS keep multitasking responsive
  • PCIe 4.0 x4 with NVMe 1.4 enables the high throughput
  • 3D NAND and 1000000 hour MTBF support long-term reliability

Specifications

BrandKingSpec
SeriesXG7000 2242 Series
ModelXG7000-512 2242
Part NumberXG7000-512 2242
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity512GB
Memory Components3D NAND
InterfacePCI-Express 4.0 x4
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 4200 MBps
4KB Random ReadUp to 630,000 IOPS
4KB Random WriteUp to 570,000 IOPS
MTBF1,000,000 hours
HeatSinkwith HeatSink
Power Consumption (Idle)0.63W
Power Consumption (Active)3.50W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5-95%
Height42.0mm
Width22.0mm
Depth3.5mm
Weight20g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I confirm the KingSpec XG7000-512 2242 is delivering its rated 7000 MBps read speed after installation?

Run a synthetic benchmark such as CrystalDiskMark on Windows 10 or 11; the sequential read result should approach 7000 MBps and write near 4200 MBps when the drive is connected to a PCIe 4.0 x4 slot.

What is included with the KingSpec XG7000-512 2242 and what must be sourced separately?

The package contains the M.2 2242 SSD with a pre-fitted heatsink; you must supply a compatible M-key motherboard slot, a mounting screw, and an operating system such as Windows 10, 11, Linux or Windows Server 2012 R2.

Which capacity from the KingSpec XG7000 2242 series should I choose for a primary OS drive?

The 512 GB model provides 512 GB of 3D NAND storage and up to 7000 MBps read speed, making it suitable for a boot drive; 1 TB and 2 TB versions exist if you need more space for applications and files.
