Green circuit board with black chips, M.2 2280 form factor, no heatsink

KingSpec

KingSpec XG7000 2280 2TB M.2 2280 PCIe 4.0 x4 NVMe 1.4 internal SSD

SKU CH-B73C-F6P64

M.2 2280 NVMe 1.4 drive delivers up to 7400 MB/s read and 6600 MB/s write with 1200 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D NAND
  • InterfacePCI-Express 4.0 x4

Options XG 7000-2TB

Struck-through versions exist but are not stocked here.

  • Sequential read up to 7400 MB/s cuts game load times
  • Sequential write up to 6600 MB/s accelerates large file saves
  • 1200 TBW rating supports heavy daily workloads
  • 1,000,000 hour MTBF indicates long operational life
  • Idle power of 0.66 W reduces laptop battery drain

2TB PCIe 4.0 NVMe drive

The KingSpec XG7000 2280 is a 2TB internal SSD built on 3D NAND with a PCIe 4.0 x4 interface and NVMe 1.4 protocol. It targets PC, laptop and PS5 users who need fast, high-capacity storage without a bulky heatsink. The M.2 2280 form factor measures 80.0mm by 22.0mm by 2.1mm, so it fits standard slots in desktops, notebooks and the console.

Capacity and sustained workloads

At 2TB the drive holds large game libraries, 4K or 8K video projects and creative asset collections with room to spare. Sequential reads reach 7400MB/s and writes 6600MB/s, while 4KB random performance hits 720,000 read IOPS and 800,000 write IOPS. The 1200TBW endurance rating and 1,000,000-hour MTBF indicate it can sustain heavy daily writes for years before wear becomes a concern.

Build integration and platform needs

The drive slots directly into any M.2 2280 key-M socket wired for PCIe 4.0 x4 and remains backward compatible with PCIe 3.0 systems. It draws 0.66W idle and 8.18W under load, so motherboard power delivery and case airflow should accommodate the active draw. No separate heatsink is included; the integrated graphene spreader handles thermal management, freeing up space around the slot for other components.

Highlights

  • Sequential read up to 7400 MB/s cuts game load times
  • Sequential write up to 6600 MB/s accelerates large file saves
  • 1200 TBW rating supports heavy daily workloads
  • 1,000,000 hour MTBF indicates long operational life
  • Idle power of 0.66 W reduces laptop battery drain

Specifications

BrandKingSpec
SeriesXG7000 Series
ModelXG7000 2280
Part NumberXG7000-2TB 2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D NAND
InterfacePCI-Express 4.0 x4
ProtocolNVMe 1.4
Max Sequential ReadUp to 7400 MBps
Max Sequential WriteUp to 6600 MBps
4KB Random ReadUp to 720,000 IOPS
4KB Random WriteUp to 800,000 IOPS
Terabytes Written (TBW)1200TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)0.66W
Power Consumption (Active)8.18W
Operating Temperature0°C ~ +70°C
Storage Temperature-25°C ~ +75°C
Operating Humidity5-95%
Height80mm
Width22mm
Depth2.1mm
Weight30g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 2.1 mm height fit my laptop or PS5 without clearance issues?

The drive measures 80.0 mm long, 22.0 mm wide and 2.1 mm high, matching the standard M.2 2280 slot used in most laptops, desktops and the PS5 expansion bay.

Does the 1200 TBW rating give enough endurance for heavy daily writes?

At 1200 TBW you could write roughly 1 TB every day for over three years before reaching the guaranteed endurance limit.

Can I use this drive in a PCIe 3.0 slot and still get usable speed?

Yes, the NVMe 1.4 interface is backward compatible with PCIe 3.0 x4; sequential reads will be limited to the 3.0 ceiling but random performance up to 720000 read and 800000 write IOPS remains strong.
