ATX motherboard in dark finish with large heatsinks, CPU socket and four DDR5 slots visible

MSI

MSI MPG X870E EDGE TI WIFI + Ryzen 5 9600X AMD motherboard CPU combo

SKU CH-6FM7-RYZF2

A motherboard and CPU combo with AM5 socket, DDR5 memory support up to 256 GB, PCIe 5.0 graphics slot, four M.2 sockets, 5 Gb LAN and Wi‑Fi 7

  • CPU Socket TypeAM5
  • CPU TypeSupports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processo
  • ChipsetAMD X870E
  • Number of Memory Slots4x288pin (DDR5)
  • Memory Standard4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support
  • Maximum Memory Supported256GB

CPU +Ryzen 5 9600X

  • Ready-to-build combo with Ryzen 5 9600X included
  • DDR5 memory up to 8400 MT/s on four slots
  • PCIe 5.0 graphics slot and two CPU-linked M.2 slots
  • 5G LAN plus Wi-Fi 7 for fast networking
  • Premium VRM cooling with heat-pipe and 7W/mK pads

Combo foundation

This bundle pairs an MSI MPG X870E EDGE TI WIFI motherboard with an AMD Ryzen 5 9600X processor. The board uses the AMD X870E chipset on an AM5 socket, supporting Ryzen 9000, 8000 and 7000 series CPUs. The included 9600X delivers 6 cores and 12 threads based on the Zen 5 architecture. It targets builders who want a matched platform for gaming and productivity without selecting parts separately.

Build integration

Four DDR5 UDIMM slots accept up to 256 GB at speeds up to 8400 MT/s overclocked or 5600 MT/s JEDEC. One PCIe 5.0 x16 slot, one PCIe 4.0 x16 slot and one PCIe 3.0 x16 slot handle graphics and add-in cards. Four SATA 6 Gb/s ports and four M.2 sockets (two CPU-linked at PCIe 5.0 x4, two chipset-linked at PCIe 4.0 x4) provide extensive storage options. Tool-less EZ PCIe Release and EZ M.2 Shield Frozr II simplify installation. Realtek ALC4080 7.1-channel audio, Realtek 8126 5G LAN and Wi-Fi 7 with 320 MHz channels complete the I/O.

Suitability check

This combo suits enthusiasts building a high-bandwidth AM5 system who value integrated 5G LAN, Wi-Fi 7 and PCIe 5.0 storage from day one. The 9600X fits mid-range gaming and multitasking workloads. Builders needing ECC memory, more than four M.2 drives, or a higher core-count CPU for sustained render workloads should consider a different processor or a workstation-class board.

Highlights

  • Ready-to-build combo with Ryzen 5 9600X included
  • DDR5 memory up to 8400 MT/s on four slots
  • PCIe 5.0 graphics slot and two CPU-linked M.2 slots
  • 5G LAN plus Wi-Fi 7 for fast networking
  • Premium VRM cooling with heat-pipe and 7W/mK pads

Specifications

BrandMSI
SeriesMPG X870E EDGE TI WIFI+R5 9600X
ModelMPG X870E EDGE TI WIFI+R5 9600X
Part NumberMPG X870E EDGE TI WIFI
CPU Socket TypeAM5
CPU TypeSupports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
ChipsetAMD X870E
Number of Memory Slots4x288pin (DDR5)
Memory Standard4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory Support DDR5 8400 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s
Ryzen™ 9000 Series Processors max. overclocking frequency:
• 1DPC 1R Max speed up to 8400+ MT/s
• 1DPC 2R Max speed up to 6400+ MT/s
• 2DPC 1R Max speed up to 6400+ MT/s
• 2DPC 2R Max speed up to 4800+ MT/s
Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPOTM
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only*
* CUDIMM support and POR boot frequency may vary by CPU series, with manua
Maximum Memory Supported256GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
PCI Express 5.0 x161 x PCI Express 5.0 x16
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI SlotsPCI_E1 slot
• Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors)
• Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
• Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor)
Serial ATA (SATA)4 x SATA 6Gb/s
M.24x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280 devices
M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
4x SATA 6G
M.2_1 slot
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors)
M.2_2 slot
• Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors)
• The M2_2 slo
Audio ChannelsRealtek® ALC4080 Codec
7.1-Channel USB High-Performance Audio
Supports up to 32-Bit/384 kHz playback on front panel
Supports S/PDIF output
Max LAN Speed1x Realtek® 8126 5G LAN
Wireless LANWi-Fi 7
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
Supports Bluetooth® 5.4**, MLO, 4KQAM
* 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.
BluetoothYes
Back I/O PortsClear CMOS Button
USB 10Gbps Type-A
USB 2.0
5G LAN
Wi-Fi / Bluetooth
Audio Connectors
Flash BIOS Button
HDMI™
USB 40Gbps Type-C
USB 10Gbps Type-A
USB 10Gbps Type-C
Optical S/PDIF Out
Other Connectors1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x Front Type-C Quick Charge Connector(PD_PWR1)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
6x System Fan
1x EZ Conn-header (JAF_2)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports
1x USB 20Gbps Type C ports
Form FactorATX
Dimensions (W x L)243.84mmx304.8mm
Windows 11Support for Windows® 11 64-bit
FeaturesSupports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Supports DDR5 Memory, Dual Channel DDR5 8400+ MT/s (OC)
Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 8-layer PCB made by 2oz thickened copper and server-grade level material
Frozr Guard: Enlarged heatsink with heat-pipe, MOSFET thermal pads rated for 7W/mk, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
EZ DIY: EZ PCIe Release, EZ M.2 Shield Frozr II, EZ M.2 Clip II and EZ Antenna
Ligh

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 128GB/s PCIe 5.0 bandwidth saturate before the CPU hits its thermal ceiling?

The board provides one PCIe 5.0 x16 slot and two CPU-attached M.2 slots at PCIe 5.0 x4 each; the Ryzen 5 9600X 6-core 12-thread processor shares that bandwidth, so sustained GPU plus dual SSD loads will reach the interface limit first.

How loud and hot does the VRM area get when the 9600X runs all day at stock settings?

The premium thermal design uses a heavy plated MOSFET heatsink with heat-pipe, 7W/mK thermal pads and extra choke pads; this keeps VRM temperatures low enough that fan noise stays minimal during extended workloads.

Which DDR5 memory kit must I already own to boot this combo?

You need DDR5 UDIMM modules; the board supports up to 256GB across four slots at JEDEC 5600-4800 MT/s or overclocked 8400-5600 MT/s with Ryzen 9000 series CPUs.
