Sky blue 90 degree rotary elbow fitting with 20mm extension, brass body, G1/4 threads

PrimoChill

PrimoChill G1/4 90° Rotary 20mm Extension Elbow Sky Blue

SKU CH-N27R-EXN43

A 90-degree rotary elbow with 20mm extension and G1/4 threads redirects tubing runs 360 degrees around components

  • TypeFittings

Option Sky Blue

Show 9 more configurations

Struck-through versions exist but are not stocked here.

  • Rotary design enables 360° alignment for flexible routing
  • 20 mm extension adds clearance around tight components
  • 90° elbow redirects tubing away from obstacles
  • Brass construction with SX powder-coated Sky Blue finish
  • G1/4 male-to-female threads fit standard water-cooling loops

Quick-Angle Loop Adapter

The PrimoChill G1/4 90° rotary elbow adds a 20mm extension and lets you redirect tubing runs 90 degrees from the mounting point. Its 360-degree rotary function allows the fitting to be aimed in any direction after installation. The brass body carries an SX powder-coated finish in Sky Blue. Total installed height measures 43mm with a 5mm thread depth.

Rigid-Tubing Clearance Fix

This fitting replaces a standard static elbow when components sit too close for a clean 90-degree turn. The 20mm standoff creates the extra height needed to clear VRM heatsinks, reservoir ports or pump tops. The jump is worth it whenever a fixed elbow forces tubing into a sharp kink or blocks access to adjacent fittings.

Thread And Clearance Check

Verify that every component in the loop uses G1/4 threads before ordering. Confirm the 43mm total height and 20mm base height fit within your case layout and do not interfere with side panels or other hardware. The rotary joint is hand-tightened; ensure the final orientation holds under system pressure without binding.

Highlights

  • Rotary design enables 360° alignment for flexible routing
  • 20 mm extension adds clearance around tight components
  • 90° elbow redirects tubing away from obstacles
  • Brass construction with SX powder-coated Sky Blue finish
  • G1/4 male-to-female threads fit standard water-cooling loops

Specifications

TypeFittings

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What thread size and extension length does this fitting use?

The fitting uses a G1/4 thread on both ends and provides a 20mm installed base height for added clearance.

How do I install the rotary elbow without stressing the O-rings?

Screw the male thread in 5mm, then rotate the 360-degree joint to the desired 90-degree angle before tightening the tubing side.

When should I replace the O-rings on this brass elbow?

Inspect the O-rings during any loop maintenance and replace them if they show flattening, cracking, or loss of elasticity.
