ATX motherboard with CPU cooler installed, dark grey and black finish

ASUS

ASUS TUF GAMING X870-PRO WIFI7 W NEO AMD motherboard Ryzen 5 9600X combo

SKU CH-WF4R-N0V07

AMD AM5 motherboard and 6-core 12-thread Ryzen 5 9600X CPU combo with DDR5, four M.2 slots, PCIe 5.0 graphics, WiFi7 and 5Gb Ethernet

  • ChipsetAMD X870
  • South BridgeAMD X870
  • Number of Memory Slots4x288pin (DDR5)
  • Maximum Memory Supported256GB
  • Channel SupportedDual Channel
  • Memory Performance ProfileAMD EXPO / Intel XMP / ASUS AEMP

Motherboard TUF GAMING X870-PRO WIFI7 W NEO

CPU + R5 9600X

  • Motherboard and CPU combo simplifies high-performance PC builds
  • 16+2+1 80 A power stages deliver stable energy for Ryzen 9000 series processors
  • Four M.2 slots with PCIe 5.0 and 4.0 support fast storage expansion
  • WiFi7 and 5 Gb Ethernet provide high-speed wired and wireless connectivity
  • 64 MB BIOS and UEFI tools enable easy updates and system tuning

Combo foundation

This bundle pairs an ASUS TUF GAMING X870-PRO WIFI7 W NEO ATX motherboard with an AMD Ryzen 5 9600X processor. The board uses the AMD X870 chipset and AM5 socket to support Ryzen 7000, 8000 and 9000 series CPUs. The included 9600X delivers 6 cores and 12 threads based on Zen 5 architecture with a 5.4 GHz max boost clock, unlocked for overclocking.

Build integration

Four DDR5 slots accept up to 256 GB in dual-channel mode with AMD EXPO, Intel XMP and ASUS AEMP profiles plus ECC support. One PCIe 5.0 x16 slot, two PCIe 4.0 x16 slots, one PCIe x16 slot and one PCIe x4 slot provide expansion headroom. Four M.2 sockets handle PCIe 5.0 x4 and PCIe 4.0 x4 drives while two SATA 6 Gb/s ports and RAID 0/1/5/10 cover legacy storage. USB4 at 40 Gbps, a 20 Gbps USB-C port with 30 W power delivery, WiFi7 and 5 Gb Ethernet complete the I/O. Q-Release mechanisms simplify M.2 and PCIe installation.

Sustained behaviour

The 16+2+1 80 A power stage design on an 8-layer PCB with 8+8 pin ProCool connectors is built for continuous delivery. AI Cooling II and AI Networking III manage thermals and traffic under prolonged load while Asynchronous Clock technology aids stability during extended overclocking sessions. Realtek ALC1220P drives 7.1-channel audio and a 64 MB BIOS with FlashBack supports long-term firmware updates.

Highlights

  • Motherboard and CPU combo simplifies high-performance PC builds
  • 16+2+1 80 A power stages deliver stable energy for Ryzen 9000 series processors
  • Four M.2 slots with PCIe 5.0 and 4.0 support fast storage expansion
  • WiFi7 and 5 Gb Ethernet provide high-speed wired and wireless connectivity
  • 64 MB BIOS and UEFI tools enable easy updates and system tuning

Specifications

BrandASUS
ModelTUF GAMING X870-PRO WIFI7 W NEO+R5 9600X
ChipsetAMD X870
South BridgeAMD X870
Number of Memory Slots4x288pin (DDR5)
Maximum Memory Supported256GB
Channel SupportedDual Channel
Memory Performance ProfileAMD EXPO / Intel XMP / ASUS AEMP
ECC SupportedYes
Buffer SupportedUn-buffered
PCI Express 5.0 x161 x PCI Express 5.0 x16
PCI Express 4.0 x162 x PCI Express 4.0 x16
PCI Express x162 x PCI Express x16
PCI Express x41 x PCI Express x4
Serial ATA (SATA)2 x SATA 6Gb/s
M.24 x M.2 (Support PCIe 5.0 x4 & PCIe 4.0 x4)
SATA RAID0/1/5/10
Onboard Video ChipsetDepends on AMD Ryzen Series Processor with Integrated Graphics
Audio ChipsetRealtek ALC1220P
Audio Channels7.1 Channels
LAN ChipsetRealtek 5Gb
Max LAN Speed5Gbps
Wireless LANWi-Fi 802.11 be
BluetoothYes
Back I/O Ports2 x USB4 (40Gbps) Type-C, 3 x USB 10Gbps Type-A, 4 x USB 5Gbps Type-A, 1 x USB 2.0 Type-A, 1 x HDMI, 1 x Wi-Fi module, 1 x Realtek 5Gb Ethernet port, 3 x Audio jacks, 1 x BIOS FlashBack button, 1 x Clear CMOS button
COM1
Video PortsHDMI + 2 x USB Type-C
HDMI1 x HDMI port
RJ451 x RJ45
USB 3.13 x USB 3.1
USB 3.06 x USB 3.0
USB 1.1/2.01 x USB 2.0
USB Type-C2 x USB Type-C port, with USB4 (40Gbps) support
S/PDIF OutYes
Audio Ports3 Ports
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 2x2 + 1 x USB 3.2 Gen 1 header + 3 x USB 2.0 headers
Form FactorATX
LED LightingRGB
Dimensions (W x L)12 inch x 9.6 inch
Power Pin24 Pin
Windows 11Supported

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How many 80A power stages does the 16+2+1 VRM use for the CPU cores?

The board uses 16 power stages rated at 80A each for the CPU cores, with 2 more for the SOC and 1 for the VDDIO rails.

What is the maximum boost clock of the included Ryzen 5 9600X under sustained all-core loads?

The processor has a maximum boost clock of 5.4 GHz, though sustained all-core speeds will depend on your cooler and case airflow.

Which DDR5 memory kits must I already own to populate the four 288-pin slots?

You need DDR5 modules; the board supports up to 256GB across four slots with AMD EXPO, Intel XMP or ASUS AEMP profiles.
