Small green mSATA circuit board with gold edge connector and black chips, 30 by 50.9 millimetres

Dogfish Technology

Dogfish Technology mSATA 60GB internal SSD

SKU CH-AR4M-38T54

An mSATA 60 GB internal SSD with 3D NAND, up to 550 MB/s read and 400 MB/s write, for SATA III laptops and desktops

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactormSATA
  • Capacity60GB
  • Memory Components3D NAND
  • InterfaceSATA III

Options 60GB mSATA

  • Up to 550 MB/s sequential read speeds for fast boot and load times
  • Up to 500 MB/s sequential write speeds for quick file saves and transfers
  • 3D NAND flash memory for higher density and enhanced reliability
  • Built-in ECC and bad-block management protect data integrity
  • DevSleep ultra-low power state extends laptop battery life

Capacity and fit

This Dogfish mSATA drive delivers 60GB of 3D NAND storage in the 30x50.9mm form factor. It targets older laptops and desktops that still rely on the mSATA slot for primary or secondary storage.

SATA III practical limits

The SATA III 6 Gb/s interface caps sequential throughput at 550 MB/s read and 500 MB/s write. Real-world speeds will sit below those ceilings because the bus itself is the bottleneck, not the flash.

Build and daily implications

Weighing 7g and measuring just 0.1mm thick, the bare board slides into the slot with no cables or brackets. No moving parts means silent operation, minimal heat, and support for DevSleep to extend battery life on portable systems.

Highlights

  • Up to 550 MB/s sequential read speeds for fast boot and load times
  • Up to 500 MB/s sequential write speeds for quick file saves and transfers
  • 3D NAND flash memory for higher density and enhanced reliability
  • Built-in ECC and bad-block management protect data integrity
  • DevSleep ultra-low power state extends laptop battery life

Specifications

BrandTHREE COLOUR DOGFISH
SeriesmSATA-60GB
ModelmSATA-60GB
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactormSATA
Capacity60GB
Memory Components3D NAND
InterfaceSATA III
ControllerSMI
Max Sequential ReadUp to 550 MBps
Max Sequential WriteUp to 500 MBps
MTBF1,000,000 hours
Operating Temperature0°C ~ +75°C
Storage Temperature-45°C ~ +85°C
Operating Humidity0% ~ 95%
Height30MM
Width50MM
Depth0.1MM
Weight7g

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I pick the 60 GB or 64 GB version of this mSATA drive?

The drive is a single 60 GB model; the 64 GB label in some listings refers to the same physical unit.

Will I actually see the 550 MB/s read speed in my laptop?

Real-world throughput is limited by the SATA III 6 Gb/s interface and the host controller, so sustained reads typically sit below the 550 MB/s ceiling.

Does the mSATA connector limit performance compared with a 2.5-inch SATA SSD?

No — the mSATA form factor uses the same SATA III 6 Gb/s interface, so the 550 MB/s read and 500 MB/s write caps are identical.
