ATX motherboard in dark grey with silver heatsinks and a silver CPU installed

MSI

MSI MAG X870E GAMING PLUS MAX WIFI Ryzen 7 9700X Combo AMD motherboard

SKU CH-AMYR-EDGRE

AM5 motherboard and Ryzen 7 9700X CPU combo with DDR5 up to 8200 MT/s, PCIe 5.0 x16, triple M.2 slots, Wi-Fi 7 and 5G LAN

  • CPU Socket TypeAM5
  • CPU TypeSupports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processor
  • ChipsetAMD X870E
  • Number of Memory Slots4x DDR5 UDIMM
  • Memory StandardMemory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JED
  • Maximum Memory Supported256GB

CPU +Ryzen 7 9700X

  • Ready for future CPU upgrades with 64MB BIOS capacity
  • Maximum CPU performance released by OC Engine clock generator
  • Graphics card changes simplified by EZ PCIe Release button
  • Tool-less M.2 installation with EZ M.2 Shield Frozr II design
  • 8Gbps wireless speed delivered by Wi-Fi 7 320MHz channel

AM5 Motherboard and Ryzen 7 9700X Combo

This bundle pairs the MAG X870E GAMING PLUS MAX WIFI motherboard with an AMD Ryzen 7 9700X processor. The board uses the AMD X870E chipset and an AM5 socket ready for Ryzen 9000, 8000 and 7000 series CPUs. It targets builders who want a high-performance gaming or workstation foundation in a single purchase.

Extended PWM Heatsink and 64MB BIOS

An extended PWM heatsink covers the power delivery to keep the CPU running at full speed under load. The 64MB BIOS ROM stores microcode for current and future AM5 processors, improving long-term compatibility. No noise or power-draw figures are supplied for this combination.

DDR5 8200 MT/s, PCIe 5.0 and Wi-Fi 7

Four DDR5 slots support up to 256GB at speeds up to 8200 MT/s when overclocked. The primary PCIe 5.0 x16 slot and one M.2 connector run at Gen5 from the CPU, while two additional M.2 slots use chipset Gen4 lanes. Onboard 5G LAN and Wi-Fi 7 with a 320MHz channel provide 5.8Gbps peak wireless throughput. EZ PCIe Release and tool-less M.2 Shield Frozr II simplify component swaps.

Highlights

  • Ready for future CPU upgrades with 64MB BIOS capacity
  • Maximum CPU performance released by OC Engine clock generator
  • Graphics card changes simplified by EZ PCIe Release button
  • Tool-less M.2 installation with EZ M.2 Shield Frozr II design
  • 8Gbps wireless speed delivered by Wi-Fi 7 320MHz channel

Specifications

BrandMSI
ModelMAG X870E GAMING PLUS MAX WIFI+R7 9700X
Part NumberMAG X870E GAMING PLUS MAX WIFI+R7 9700X
CPU Socket TypeAM5
CPU TypeSupports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
ChipsetAMD X870E
Number of Memory Slots4x DDR5 UDIMM
Memory StandardMemory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s
Ryzen 9000 Series Processors max. overclocking frequency:
1DPC 1R Max speed up to 8200+ MT/s
1DPC 2R Max speed up to 6400+ MT/s
2DPC 1R Max speed up to 6400+ MT/s
2DPC 2R Max speed up to 6000+ MT/s
Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPO
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only*
CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail
Maximum Memory Supported256GB
Channel SupportedDual Channel
ECC SupportedNon-ECC
Buffer SupportedUn-buffered
PCI Express 5.0 x16PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E1 slot
Supports PCIe 5.0 x16 (For Ryzen 9000/ 7000 Series processors)
Supports PCIe 4.0 x8 (For Ryzen 8700/ 8600/ 8400 Series processors)
Supports PCIe 4.0 x4 (For Ryzen 8500/ 8300 Series processor)
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express 3.0 x160 x PCI Express 3.0 x16
PCI Express x162 x PCI Express x16
PCI Express x11 x PCI Express x1
Serial ATA (SATA)4x SATA 6G
M.23 x M.2 (Support PCIe 5.0 x4 & PCIe 4.0 x4)
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices
M.2_1 slot (From CPU)
Supports up to PCIe 5.0 x4 (For Ryzen 9000/ 7000 Series processors)
Supports up to PCIe 4.0 x4 (For Ryzen 8000 Series processors)
M.2_2 slot (From CPU)
Supports up to PCIe 4.0 x4 (For Ryzen 9000/ 8700/ 8600/ 8400/ 7000 Series processors)
M.2_3 slot (From CPU)
Supports up to
Audio ChipsetRealtek ALC897
Audio Channels7.1 Channels
LAN ChipsetRealtek 8126VB
Max LAN Speed5Gbps
BluetoothYes
Back I/O Ports4 x USB 2.0
2 x USB 5Gbps Type A
2 x USB 10Gbps Type A
1 x USB 20Gbps Type C
1 x USB 40Gbps Type C
1 x HDMI
HDMI1 x HDMI
DisplayPort1 x DisplayPort
Onboard USB1 x USB Type-C header, with USB 3.2 Gen 2x2 + 4 x USB 3.2 + 6 x USB 2.0
Other Connectors1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
6x System Fan
1x EZ Conn-header (JAF_1)
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Tuning Controller connector(JDASH)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
2x Direct OC Jumper (JBCLK)
Form FactorATX
LED LightingNone RGB
Dimensions (W x L)243.84mm x 304.8mm
Windows 11Supported
Features4x EZ Debug LED
1x EZ Memory Detection LED

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the M.2 SSD in the PCIe 5.0 slot without a screwdriver?

Use the EZ M.2 Shield Frozr II tool-less latch to secure the 2280 or 2260 drive directly onto the M.2_1 slot sourced from the CPU.

What component will need replacement after extended heavy loads?

The extended PWM heatsink and M.2 Shield Frozr II are passive; no scheduled replacement is required under normal operation.

Which thermal limit appears first when the Ryzen 7 9700X runs sustained all-core workloads?

The VRM heatsink and M.2 Shield Frozr II are designed to keep the 9000 series CPU and PCIe 5.0 SSD within spec during prolonged use.
