Rectangular green circuit board with gold edge connector and black controller chips

Solidigm

Solidigm D5-P5336 15.36TB E3.S 7.5mm PCIe 4.0 enterprise SSD SBFPFABV153T001

SKU CH-VJ69-J8Z0F MPN SBFPFABV153T001

Enterprise E3.S 7.5mm SSD with 15.36TB QLC capacity, PCIe 4.0 x4, 7000 MB/s reads and 0.51 DWPD endurance

  • Form FactorE3.S 7.5mm
  • Capacity15.36TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 7000 MBps
  • Max Sequential WriteUp to 3000 MBps

Option 15.36TB E3.S

Show 21 more configurations

Struck-through versions exist but are not stocked here.

  • Massive 15.36TB capacity fits dense server racks
  • PCIe 4.0 x4 delivers up to 7000 MBps sequential read speed
  • 192-layer QLC 3D NAND enables high endurance of 14.11 PBW
  • 2,000,000-hour MTBF ensures long-term data-centre reliability
  • E3.S 7.5mm form factor optimises space in 1U chassis

Solidigm D5-P5336 15.36TB enterprise SSD

The Solidigm D5-P5336 is a 15.36TB enterprise solid-state drive built on 192-layer QLC 3D NAND. It uses the E3.S 7.5mm form factor and a PCI-Express 4.0 interface for high-density storage in data-centre servers. The drive delivers up to 7000 MBps sequential read and 3000 MBps sequential write, with 1005000 random read IOPS and 29900 random write IOPS at queue depth 256. It is rated for 0.51 drive writes per day and 14.11 PBW total endurance.

Check E3.S 7.5mm slot and PCIe 4.0 support

Verify that your server chassis has an E3.S 7.5mm drive bay and that the backplane or riser provides a PCI-Express 4.0 x4 electrical connection. Confirm the platform firmware can recognise a 15.36TB namespace and that the power budget accommodates 21W active and 5W idle consumption. Ensure the operating environment stays within 0°C to 70°C and that shock or vibration levels do not exceed 1000 G at 0.5 msec or 2.17 GRMS operating vibration.

Fits high-capacity read-heavy arrays

This drive fits dense storage arrays where read throughput and capacity per slot matter more than write endurance. Its 15.36TB capacity frees physical bays compared with lower-density drives, while the PCIe 4.0 interface supplies bandwidth for parallel workloads. The 90g weight and E3.S 7.5mm height allow tight packing in 1U or 2U enclosures. It is not suited for workloads needing higher write endurance or for systems lacking native E3.S hot-plug support.

Highlights

  • Massive 15.36TB capacity fits dense server racks
  • PCIe 4.0 x4 delivers up to 7000 MBps sequential read speed
  • 192-layer QLC 3D NAND enables high endurance of 14.11 PBW
  • 2,000,000-hour MTBF ensures long-term data-centre reliability
  • E3.S 7.5mm form factor optimises space in 1U chassis

Specifications

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV153T001
Form FactorE3.S 7.5mm
Capacity15.36TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random Read1005000 IOPS (4K, QD256)
4KB Random Write29900 IOPS (16K, QD256)
Endurance0.51 DWPD (16K RW) / 14.11 PBW
MTBF2,000,000 hours
Power Consumption (Idle)5W
Power Consumption (Active)21W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Shipping weight0.17 kg
Package size140 × 110 × 17 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the E3.S 7.5mm drive ship with a mounting bracket or heatsink?

The drive is supplied as a bare E3.S 7.5mm module; mounting hardware and any heatsink must be sourced separately for your server chassis.

Why choose the 15.36TB QLC model over a smaller TLC alternative?

The 15.36TB capacity maximises density per E3.S slot using 192-layer QLC 3D NAND, delivering 0.51 DWPD endurance suited to read-intensive workloads.

What does the 7000 MBps sequential read mean in a PCIe 4.0 x4 server?

The 7000 MBps read and 3000 MBps write saturate the PCIe 4.0 x4 link, while 1005000 random read IOPS and 29900 random write IOPS handle heavy queue depths.
