Solidigm D5-P5336 30.72TB E3.S 7.5mm enterprise SSD, bare circuit board with gold edge connector, green PCB

Solidigm

Solidigm D5-P5336 30.72TB E3.S 7.5mm PCIe 4.0 enterprise SSD SBFPFABV307TOF1

SKU CH-1QB3-HS7YK MPN SBFPFABV307TOF1

E3.S 7.5mm PCIe 4.0 enterprise SSD with 30.72TB QLC 3D NAND, 7000 MBps read, 3000 MBps write and FIPS security

  • Form FactorE3.S 7.5mm
  • Capacity30.72TB
  • Memory Components192 L QLC 3D NAND
  • InterfacePCI-Express 4.0
  • Max Sequential ReadUp to 7000 MBps
  • Max Sequential WriteUp to 3000 MBps

Option 30.72TB E3.S FIPS

Show 21 more configurations

Struck-through versions exist but are not stocked here.

  • 72 TB capacity stores massive datasets
  • PCIe 4.0 x4 delivers 7000 MBps sequential read
  • 192-layer QLC 3D NAND enables high-density storage
  • FIPS security protects sensitive enterprise data
  • 2,000,000-hour MTBF ensures long-term reliability

Capacity and form factor

The Solidigm D5-P5336 is a 30.72TB enterprise solid-state drive built in the E3.S 7.5mm form factor. It targets data-centre operators who need high-capacity flash for read-intensive workloads such as content delivery, analytics and warm-tier storage. The drive uses 192-layer QLC 3D NAND and connects through a PCI-Express 4.0 x4 interface. It is not suited for write-heavy applications that demand higher endurance.

Build integration

The E3.S 7.5mm form factor fits hot-plug bays designed for the E3.S standard, freeing the 2.5-inch or U.2 slots that older drives occupy. A PCIe 4.0 backplane or retimer card is required to reach the stated throughput. The drive draws 5W idle and 23W active, so the chassis power budget and cooling must accommodate that load. FIPS encryption is built in, removing the need for a separate self-encrypting drive controller in compliant deployments.

Sustained behaviour

Sequential reads reach 7000 MBps and writes reach 3000 MBps, while 4KB random reads hit 1005000 IOPS and 16K random writes hit 39200 IOPS at queue depth 256. Endurance is rated at 0.56 DWPD, equating to 31.55 PBW over the warranty period. MTBF is 2,000,000 hours. The controller throttles to stay within the 0°C to 70°C operating window, so sustained write streams will settle below peak burst rates once thermal limits are reached.

Highlights

  • 72 TB capacity stores massive datasets
  • PCIe 4.0 x4 delivers 7000 MBps sequential read
  • 192-layer QLC 3D NAND enables high-density storage
  • FIPS security protects sensitive enterprise data
  • 2,000,000-hour MTBF ensures long-term reliability

Specifications

BrandSolidigm
ModelD5-P5336
Part NumberSBFPFABV307TOF1
Form FactorE3.S 7.5mm
Capacity30.72TB
Memory Components192 L QLC 3D NAND
InterfacePCI-Express 4.0
Max Sequential ReadUp to 7000 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random Read1005000 IOPS (4K, QD256)
4KB Random Write39200 IOPS (16K, QD256)
Endurance0.56 DWPD (16K RW) / 31.55 PBW
MTBF2,000,000 hours
SecurityFIPS
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight90g +/- 10g
Shipping weight0.17 kg
Package size140 × 110 × 17 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How long will the 30.72TB drive last at its rated 0.56 DWPD endurance?

The drive is rated for 31.55 PBW total bytes written, which equals 0.56 drive writes per day over the warranty period.

What are the idle and active power figures for this E3.S 7.5mm SSD?

Idle power is 5W and active power reaches 23W, with an operating temperature range of 0°C to 70°C.

Does the server backplane need to accept an E3.S 7.5mm form factor and provide PCIe 4.0 x4 lanes?

Yes, the drive uses the E3.S 7.5mm form factor and requires a PCI-Express 4.0 x4 connection to operate.
